ASSEMBLY INSTRUCTIONS
MODEL 50-612ES
SUPPLIER CODE: PMEX
6 Cube Organizer, Espresso
CUSTOMER SERVICE
For fastest service on claims, requests for replacement parts, or
questions, please visit our website at
www.comfortproducts.net/support
e-mail: customerservice@comfortproducts.net
Keep your sales receipt as documentation of your ownership.
Advertisement
Related Manuals for Onespace 50-612ES
Summary of Contents for Onespace 50-612ES
- Page 1 ™ OneSpace is a Trademark of Comfort Products, Inc. ASSEMBLY INSTRUCTIONS MODEL 50-612ES SUPPLIER CODE: PMEX 6 Cube Organizer, Espresso CUSTOMER SERVICE For fastest service on claims, requests for replacement parts, or questions, please visit our website at www.comfortproducts.net/support e-mail: customerservice@comfortproducts.net...
- Page 2 Top maximum weight capacity =40lbs Shelf maximum weight capacity =10lbs 2 OF 11...
-
Page 3: Cleaning And Care
DESCRIPTION DESCRIPTION PART STOCK NO PART STOCK NO Side Panel Left 51-612ESA Lower Shelf Panel 51-612ESF Center Panel Top Side Panel Right 51-612ESB 51-612ESG and Bottom 51-612ESH Top Panel 51-612ESC Center Panel Middle Back Panel 51-612ESJ Bottom Panel 51-612ESD Upper Shelf 51-612ESE Panel HARDWARE KIT... - Page 4 NOTE: Many of the boards are similar in appearance. Pay close attention to the di erences between the boards as well as to the placement of the bolts. & Lower Shelf Panel (6), Center Panel Top and Bottom (7) and Center Panel Middle (8). Part # C x 14 Top Panel (3), Upper Shelf Panel (5) and Lower Shelf Panel (6).
- Page 5 Use two CSK Screws (D) to attach the Upper Shelf Panel (5) and Center Panel Top (7). Make sure that the grooves for the Back Panel are aligned. Also, make sure that the bolts are facing out and all the grooves are at the bottom as shown below.
- Page 6 With a screwdriver tighten two CSK Screws (D) to attach the Lower Shelf Panel (6) to Center Panel Middle (8). Make sure that the grooves for the Back Panel are aligned. Part # D x 2pcs to Lower Shelf Panel (6). While doing this make sure that the grooves for the Back Panel are aligned. Part # B x 2pcs Part # E...
- Page 7 Step 7: Slide in one Back Panel (9) with the nished side facing inside the cube. Note that the panels are not square. The long side should meet with the groove of Center Panel Middle (8). Step 8: NOTE: When attaching a side panel as shown below, you may need to push on the back panel to align it with the groove in the side panel.
- Page 8 Step 9: clockwise and then cover them with Cam Caps (E). Part # B x 4pcs Part # E x 4pcs Step 10: Slide in one Back Panel (9) with the nished side facing inside the cube. Note the orientation of the long and short sides in the drawing below.
- Page 9 Step 11: Use six CSK Screws (D) to attach the Bottom Panel (4) to Side panel Left (1), Side panel Right (2) and Center Panel Bottom (7). Make sure that the groove in the Bottom Panel (4) is aligned with the Back Panel (9). Part # D x 6pcs Step 12:...
- Page 10 Step 13: Attach the Top Panel (3) to the Side Panel Left (1), Side Panel Right (2) and Center Panel Top (7). While clockwise and then cover them with Cam Caps (E). Part # B x 6pcs Part # E x 6pcs 10 OF 11...
- Page 11 10 pounds for the shelves and 40 pounds for the top panel. For claims or questions concerning this warranty, please visit: www.comfortproducts.net or email us at: customerservice@comfortproducts.net MODEL: 50-612ES Comfort Products, Inc. 122 Gayoso Avenue, Suite 101 Memphis, TN 38103 www.comfortproducts.net customerservice@comfortproducts.net ™ OneSpace is a Trademark of Comfort Products, Inc. 11 OF 11...
