- Page 1 ™ OneSpace is a Trademark of Comfort Products, Inc. ASSEMBLY INSTRUCTIONS MODEL # 50-JN01 SUPPLIER CODE: JNFF MOBILE LAPTOP COMPUTER DESK, DUAL SURFACE...
- Page 2 weight capacity = 10lbs weight capacity = 15lbs 2 OF 7...
-
Page 3: Cleaning And Care
PARTS AND HARDWARE LIST (50-JN01) EXTRA HARDWARE INCLUDED FOR YOUR CONVENIENCE. ITEMS ARE NOT SHOWN TO SCALE. DESCRIPTION DESCRIPTION PART STOCK NO PART STOCK NO 51-JN01CV Base Cover 51-JN01LB Laptop Board 51-JN01PA Pivot Anchor 51-JN01MB Mouse Pad Board U Bracket... - Page 4 ASSEMBLY INSTRUCTION (50-JN01) DO NOT TIGHTEN SCREWS UNTIL COMPLETELY ASSEMBLED STEP 1 Screw the Locking Casters (H) into the middle legs of the Base (C). Screw the Non-locking Casters (G) into the outer legs of the Base. Attach the Center Bar (D) to the Base using four Screws (1). NOTE: The holes at the top of the Center Bar should be facing the shorter end of the Base.
-
Page 5: Assembly Instruction
ASSEMBLY INSTRUCTION (50-JN01) DO NOT TIGHTEN SCREWS UNTIL COMPLETELY ASSEMBLED STEP 3 Attach the Pivot Anchor (J) to the Laptop Board (A) using two Screws (3). Attach the Top Support (E) to the Laptop Board (A) using the U Bracket (K) and two Screws (3). - Page 6 ASSEMBLY INSTRUCTION (50-JN01) DO NOT TIGHTEN SCREWS UNTIL COMPLETELY ASSEMBLED STEP 5 Insert the Top Support (E) into the Center Bar (D). Secure it at the desired height using the Support Knobs (N) . 6 OF 7...
- Page 7 10 pounds. For claims or questions concerning this warranty, please visit www. comfortproducts.net /support or e-mail us at customerservice@comfortproducts.net MODEL : # 50-JN01 Comfort Products, Inc. P.O. Box 999 Memphis, TN 38101 www.comfortproducts.net customerservice@comfortproducts.net ™ OneSpace is a Trademark of Comfort Products, Inc. 7 OF 7...
