Adjustment
1
Bobbin winder
.05.22
● Adjust drive wheel 1 (screw 2) in accordance with the requirement.
30
Requirement
1. When the bobbin winder is engaged, the winding spindle must be driven reliably.
When it is disengaged, friction wheel 3 should not be touching drive wheel 1.
2. When it is switched off, the bobbin winder must click securely into its end position
(knife raised).
Fig. 1 - 22
1
3
2
