Adjustment
1 Needle position crosswise to sewing direction
.05.10
● Turn screws 1 (screws 2, on both sides of the post) according to the requirement.
18
Requirement
As seen crosswise to the sewing direction, the needle must penetrate in the centre of
the needle hole.
2
4
2
Fig. 1 - 10
Ensure that support plate 3 is parallel to hook post 4.
(on the PFAFF 2571 ME)
2
1
3
2
