Modular Video Wall Headers Installation
MVWS-3X3 SERIES
1/2"-13 Washer (Qty. 8)
Lifting Shackle (Qty. 4)
1/2"-13 Nut (Qty. 8)
1/2"-13 Bolt (Qty. 8)
ying header assembly
MVWS-2X2 SERIES
1/2"-13 Washer (Qty. 6)
Lifting Shackle (Qty. 2)
1/2"-13 Nut (Qty. 6)
1/2"-13 Bolt (Qty. 6)
ying header assembly
*Hardware and components for hanging are not provided with header.
Note: properly quali ed installation personnel and hardware are strongly recommend
when ying video walls to ensure proper compliance with local codes.
