leverage
Installation Guides
Section:
MOUNTED STORAGE AND ACCESSORIES
Description:

OVERHEAD UPMOUNT INSTALLATION

Overhead Upmount (KSU)
Date:
May 2020
TLE_406
Part and Product Identification
A - Overhead Body with Overhead
Upmount Back Panel Assembly
(KSF) x1
B - Overhead Upmount Bracket RH/LH
(A15-8024R/L) x1
C - Bracket Retainer Clip
(B07-0147) x2
D - Machine Screws 1/4-20 x 1"
Pax, Quadrex, Black
(E0-0081) x4
Page No:
1 of 3
Rev. No: 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the leverage and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Teknion leverage

  • Page 1 Installation Guides Section: MOUNTED STORAGE AND ACCESSORIES Date: May 2020 Page No: 1 of 3 Description: OVERHEAD UPMOUNT INSTALLATION TLE_406 Rev. No: 1 Overhead Upmount (KSU) Part and Product Identification A - Overhead Body with Overhead Upmount Back Panel Assembly...
  • Page 2 Installation Guides Section: MOUNTED STORAGE AND ACCESSORIES Date: May 2020 Page No: 2 of 3 Description: OVERHEAD UPMOUNT INSTALLATION TLE_406 ASSEMBLE NUT AND BOLT ARRANGEMENT MOUNT THE SCREEN STEP 1: Assemble Nut and Bolt arrangement as illustrated. STEP 2: Mount the Screen onto one of the Slots in Table Rail as illustrated.
  • Page 3 Installation Guides Section: MOUNTED STORAGE AND ACCESSORIES Date: May 2020 Page No: 3 of 3 Description: OVERHEAD UPMOUNT INSTALLATION TLE_406 SECURE THE SCREEN STEP 3: Secure the Screen by rotating the T-Nuts from Horizontal position to Vertical position by using Allen Key as shown.
