Operator Seat
Safety, Operation, Maintenance, &
Parts Manual
OS96
rev. A.00 - H.00
Safety is our #1 concern! Read and understand
all safety information and instructions before oper-
ating, setting up or maintaining this machine.
April 1997
Form #902

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OS96 and is the answer not in the manual?

Questions and answers

Related Manuals for Wood-mizer OS96

Summary of Contents for Wood-mizer OS96

  • Page 1 Operator Seat Safety, Operation, Maintenance, & Parts Manual OS96 rev. A.00 - H.00 Safety is our #1 concern! Read and understand all safety information and instructions before oper- ating, setting up or maintaining this machine. April 1997 Form #902...

  • Page 2: Table Of Contents

    Table of Contents Section-Page SECTION 1 OPERATION Overview ....................1-1 Installation ....................1-2 Towing The Sawmill With Seat ............1-10 Seat Roller ReplacementMaintenance..........1-12 SECTION 2 REPLACEMENT PARTS Seat/Arm Rest..................2-1 Upper Roller Bearings................2-2 Lower Roller Bearings ................2-3 Seat Frame/Latch/Travel Pin..............2-4 INDEX 96OS97doc020113Table of Contents...

  • Page 3: Operation

    Operation Overview SECTION 1 OPERATION Overview The operator seat is compatible with all ‘92 through ‘96 model LT30, LT40, LT30HD, LT40HD, LT60HD and LT70HD standard and super mills. The seat allows the operator to be seated while traveling with the saw head. NOTE: The seat reduces maximum cutting length by 25".

  • Page 4: Installation

    Operation Installation Installation CAUTION! (Hydraulic Models Only). Move the saw car- riage forward until the power supply contact button is disen- gaged from the hydraulic power strip. Disconnect the negative (-) battery cable before performing service near the hydraulic power supply. Failure to disconnect the cable could cause damage to the electrical system.
  • Page 5 Operation Installation 3. Remove the two step retaining pins and lower the foot step. Replace the retaining pins. See Figure 1-3. 3H0104 FIG. 1-3 Flip foot step down Remove retaining pins Install seat to sawmill 3H0863-5B FIG. 1-3 Operation 96OS-969700doc020113...
  • Page 6 Operation Installation 4. Secure the seat in place by tightening the lower roller adjustment bolts until the lower roll- ers just touch the bottom bed rail. DO NOT OVERTIGHTEN! The seat should roll freely when properly installed. 96OS-969700doc020113 Operation...
  • Page 7 Operation Installation 5. Position the lower rollers on each side of the bottom bed rail. Turn the seat adjustment knobs in as far as they will go, then back them out 1/2 turn to prevent overtightening. See Figure 1-4. Lower rollers around bottom track rail Adjustment knob...
  • Page 8 Operation Installation Lower Rollers touch bottom rail 3H0531B Loosen Jam Nut Adjustment Bolt FIG. 1-4 6. Remove the fender on the operator’s side of the sawmill. 96OS-969700doc020113 Operation...
  • Page 9 Operation Installation 7. Check that both lower end rollers are touching the track and sharing the weight of the seat evenly. See Figure 1-5. 8. If one end roller has more pressure than the other, adjust the eccentric roller until both end rollers have equal pressure.
  • Page 10 Operation Installation 10. Connect the seat to the sawmill carriage. Lift up on the seat latch, and move the seat in toward the carriage until the latch hook is underneath the track roller housing. Release the latch. See Figure 1-6. Make sure the seat is securely fastened to the carriage and there is no looseness between the seat and the sawmill carriage.
  • Page 11 Operation Installation 12. Install the tool box to the seat frame. Use the hardware supplied in the tool box to mount the box to the holes located directly behind the seat. See Figure 1-7. 5/16-18 x 3/4” Hex Head Bolt (2) 5/16”...

  • Page 12: Towing The Sawmill With Seat

    Operation Towing The Sawmill With Seat Towing The Sawmill With Seat 1. Move the saw head to its towing position. 2. Disconnect the seat from the sawmill carriage by pulling up on the seat latch and pulling back on the seat. Move the seat back past the trailer wheel until the travel lock pin aligns with the hole in sawmill frame tube.
  • Page 13 Operation Towing The Sawmill With Seat 7. After you have marked the location, pull the pin out, rotate the 1/2 turn, and release into the pin resting bracket. Move the seat slightly forward to allow access to the hole location. Start a 5/8”...

  • Page 14: Seat Roller Replacementmaintenance

    Operation Seat Roller ReplacementMaintenance Seat Roller ReplacementMaintenance When replacing seat roller bearings, be careful not to overtighten the nuts that secure the bearings to the frame. CAUTION! Overtightening the seat roller nuts may damage the threads on the bearing stud and/or the nut. Maximum torque used to tighten the nuts is 65 ft.-lbs.

  • Page 15: Replacement Parts

    3H0511-1 DESCRIPTION Indicates Parts Available In Assemblies Only) PART # QTY. OPERATOR SEAT OPTION, COMPLETE (Includes all parts in Sections 2.1 - 2.4) OS96 Arm Rest, Operator Seat W11340 Screw, #10 x 1” Hex Washer Head Self-Tapping F05015-21 Seat, Operator P11334 Bolt, 5/16-18 X 1/2"...

  • Page 16: Upper Roller Bearings

    Upper Roller Bearings Upper Roller Bearings 3H0511-3B DESCRIPTION Indicates Parts Available In Assemblies Only) PART # QTY. ROLLER KIT, OS96 DOUBLE BEARING REPLACEMENT 071237 Bolt, 7/16-14 X 2 1/2" Hex Head F05007-140 Bearing, 1-1/2 Cam 071238 Spacer, Operator Seat Roller...

  • Page 17: Lower Roller Bearings

    PART # QTY. BRACKET ASSEMBLY, OPERATOR SEAT LOWER ROLLER MOUNT W11325 Bracket Weldment, Operator Seat Lower Roller Mount W11324 Roller Kit, OS96 Heavy Duty Bearing Replacement 071237 Bolt, 7/16-14 X 2 1/2" Hex Head F05007-140 Bearing, 1-1/2 Cam 071238 Spacer, Operator Seat Roller...

  • Page 18: Seat Frame/Latch/Travel Pin

    Replacement Parts Seat Frame/Latch/Travel Pin Seat Frame/Latch/Travel Pin 3H0511-2 DESCRIPTION Indicates Parts Available In Assemblies Only) PART # QTY. FRAME WELDMENT, OPERATOR SEAT W11319 PIN, OPERATOR SEAT TRAVEL LOCK S11335 SPRING, OPERATOR SEAT TRAVEL PIN P04282 WASHER, 1/2" SAE FLAT F05011-2 PIN, 1/8"...

  • Page 19: Index

    INDEX installation maintenance 1-12 replacement parts frame, latch & travel pin lower roller bearings seat/arm rest upper roller bearings towing sawmill with seat 1-10 Index 96OS97doc020113...
