ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM7779CK/EK-VN
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Wrench
2 PERSONS RECOMMENDED
Page 1 of 6
(Included)
(Included)
Rev: 19-06-26
Advertisement
Table of Contents
Related Manuals for Furniture of America CM7779CK-VN
Summary of Contents for Furniture of America CM7779CK-VN
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM7779CK/EK-VN ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench assembling a specific product (with 1 being (Included) easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 6...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 2pcs Headboard Bolt Ø5/16" x 2-1/2" #2 x 2pcs #B x 8pcs Threaded Stud Ø5/16"...
- Page 4 Exploded View Align legs (#4) to footboard (#3), then secure by using bolts (#A) with washers (#C,D). #A x 2pcs #C x 2pcs #D x 2pcs Page 4 of 6...
- Page 5 Attach threaded bolts (#B) to headboard (#1) and footboard (#3), then align side rails (#2) to the threaded bolts (#B) of the headboard (#1) and footboard (#3). Secure by using hex nuts (#H) with washers (#C,E). #B x 8pcs #C x 8pcs #E x 8pcs #H x 8pcs Attach support legs (#5) to slats (#6).
- Page 6 Align slats (#6) to the side rails (#2), then secure by using screws (#G). #G x 8pcs ASSEMBLY IS COMPLETED Page 6 of 6...
