- Page 6 1) Align side rails (#2) to the holes of the footboard (#3). Insert bolts (#B) to the back holes of the footboard (#3), then half tighten with washer (#C) and nuts (#D) through the interior of the footboard (#3). Hook side rails (#2) to the bolts (#B), then fully tighten.
- Page 7 Align wheels (#K) to each end of the front trundle (#4) and back trundle (#5). Secure with screws (#G). Prepare 8 bolts assembly by inserting washer (#C) onto bolts (#A). Align side trundles (#6) to the holes of the front (#4) and back trundle (#5). Secure with bolts (#A).
- Page 8 Align the crossbars (#7) to the holes of the trundle front (#4) and back (#5) as shown in the picture. Secure with screws (#E). Insert wood dowels (#J) to the holes of the front drawer (#8) as shown in the picture. Align the side drawer panels (#9) to the wood dowels of the front drawer (#8).
- Page 9 Align back drawer (#11) to the holes of the side drawer (#9). Secure with screws (#F). Align scroll bar (#L) to the holes on the bottom of the drawers. Secure scroll bar (#L) holes of back drawer then secure with screws (#I). Secure scroll bar (#L) holes of front drawer, then secure with screws (#H).
- Page 10 Slide the bottom scroll bar (#L) through the crossbars (#7) of the trundle. Make sure it is in place. Align twin slats (#12) to the trundle, then secure with screws (#E)
