For more information contact our team: service.ec@foagroup.com
ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM7725CK/EK/Q/F
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of 7
(Included)
(Included)
(Not Included)
Rev: 16-11-28
Advertisement
Related Manuals for Furniture of America CM7725CK
Summary of Contents for Furniture of America CM7725CK
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM7725CK/EK/Q/F ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that Allen Wrench shows the degree of effort needed in (Included) assembling a specific product (with 1 being Wrench easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 7...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 4pcs Bolt Ø5/16" x 2" Headboard Panel #2 x 1pc #B x 4pcs Lock Washer Ø5/16"...
- Page 4 #I x 8pcs #M x 12pcs Hex nut Ø5/16" x 3/4" Slats connector #J x 2pcs #N x 24pcs Screw #4 x 1-1/4" End Cap #K x 1pc #O x 1pc Open Wrench U wood bar #L x 1pc Allen Wrench Prepare 4 bolts assembly by inserting lock washer (#B), then flat washer (#C) onto bolts (#A).
- Page 5 1) Attach the thread bolts (#G) to the headboard (#1) and footboard (#2). Place curve washer (#H), then hex nut (#I) into the bolts of the bed rails (#3). # G x 8pcs #H x 8pcs #I x 8pcs 2) Align thread bolt (#G) to the holes of the curve washer (#H) and hex nut (#I), then secure by using the wrench (#K).
- Page 6 Align U wood bar (#O) to the holes of the footboard (#2). Secure with bolts (#D). # D x 2pcs # O x 1pc Place center slat (#6) onto the U wood bars, then secure with screws (#J). # J x 2pcs Page 6 of 7...
- Page 7 Attach 1 end cap (#N) to each bed slat (#7), then connect two slats (#7) using slat connectors (#M). Secure by pushing in the caps (#M,N) to the holes of the rails (#3,6). #M x 12pcs #N x 24pcs ASSEMBLY IS COMPLETED Page 7 of 7...
