CM7777M
CM7777D
DRESSER AND MIRROR ARE SOLD AND PACKED SEPARATELY
ASSEMBLY RATING
Tools Required for Assembly:
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
Allen Wrench
(Included)
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
DIFFICULT
EASY
2 PERSONS RECOMMENDED
Page 1 of 4
Rev.14-06-16
Advertisement
Table of Contents
Related Manuals for Furniture of America Palomino CM7777M
Summary of Contents for Furniture of America Palomino CM7777M
- Page 1 Assembly Instructions CM7777M CM7777D DRESSER AND MIRROR ARE SOLD AND PACKED SEPARATELY ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult).
- Page 2 Page 2 of 4...
- Page 3 Before you begin, please read Page 2 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Hardware List Parts List #A x 6 pcs #1 x 1 pc Bolt 1/4”x1-3/8” Mirror #B x 6 pcs #2 x 2 pcs Flat Washer Mirror Support Rail...
- Page 4 The two mirror support rails (#2) are already attached behind the dresser (#3). Position the mirror support rails (#2) vertically to align with the pre-drilled holes of the dresser (#3) AND the mirror (#1). II. Prepare 6 bolt assemblies by inserting FIRST the lock washer (#C) onto the bolt (#A) and then the flat washer (#B) onto the SAME bolt (#A), in that order.
