Overland Storage ARCvault Series Remove & Replace Instructions

ARCvault Series
Shuttle Assembly Spare
Remove & Replace Instructions
IMPORTANT: Overland Storage requires that ARCvault
parts be removed and replaced by an Overland Storage
authorized service provider. Improper installation may
result in damage which voids existing warranties.
This document describes how to remove and replace a
Shuttle assembly in an Overland ARCvault Series library.
WARNING: To reduce the risk of electric shock or
damage to equipment, disconnect the power by
unplugging the power cord.
WARNING: It is recommended that a mechanical
lifter (or at least two people) be used to prevent
injury during rack removal and reinsertion.
CAUTION: Be sure all screws and washers are accounted for
during this procedure. A loose object can cause the library not
to function.
CAUTION: Do not over-torque the shuttle carriage screws when
installing the new shuttle! Use only 2-3 IN LB of torque.

Remove Magazines

To lower the weight of the unit, remove the magazines
before removing the unit from the rack.
CAUTION: Keep a loaded magazine level. Tilting the magazine
can result in the tapes falling out. Also, don't hold a magazine
by just the handle; use both hands to support it.
NOTE: If unable to power up the library, refer to the ARCvault
user guide for instructions on removing magazines manually.
1. Press Utilities > Service > Access All Mags > OK (at
the going offline message) > Unlock All.
2. Open the doors and remove all the magazines.
Part Number 10400068-101 03/2007
TM
Overview & Notes

Unpacking

Carefully unpack and verify that you have all the parts:
In addition, you will need a #1 magnetic Phillips
screwdriver. You may also need the Magazine Removal
Tool (MRT) from the Accessory Kit (or equivalent).

Electrostatic Discharge Information

To help prevent Electrostatic Discharge (ESD) damage,
observe these and other standard ESD precautions:
Preparing the Library
3. Close the doors.
4. Press Relock All and OK at the removal message.
5. Press Back three times.
6. Press Power > Power Off Library > OK (at the

Remove Unit from Rack

1. At the rear, remove the power cord and all cables.
2. At the front, loosen the retaining screws inside the
3. Using either a mechanical lifter or at least two people,
©2007 Overland Storage, Inc.
• Shuttle assembly
• Two 4-20x5/16 screws
• Four M2x4mm screws
• These remove & replace instructions
IMPORTANT: If the shuttle still contains a tape cartridge,
contact Overland Technical Support for information on
removing it.
• Use a wrist strap and properly-grounded tools.
• Make sure you are always properly grounded.
• Avoid touching pins, leads, or circuitry.
power down message) to power down the unit.
front doors.
remove the ARCvault unit from the rack and place it
on a secure, flat surface.
