US Robotics Wireless USB Print Server User Manual page 97

Wireless USB Print Server User Guide
3. Select Connect to a printer on the Internet or on your Intranet and enter
the URL of the IPP Server as follows, where ip_address represents the IP
Address of the IPP Server and 631 is the port number.
Port 1
These entries are case sensitive. They must be entered as shown,
with ipp in lower case, and P1 in UPPER case.
4. If the connection can be established and the printer on that port is online, the
following dialog will be displayed:
5. Click OK and then select the printer manufacturer and model to match the
printer connected to the port on the IPP Server.
6. Click Next and complete the Wizard. The IPP printer is now ready for use.
Using IPP Printers
The IPP Printer can be selected and used like any other Windows printer. If the IPP
Server is not on your network, your Internet connection needs to be active.
If using the supplied IPP Client software, you can use the Query IPP Printer program
installed with Add IPP Port to check the availability of the remote IPP Server.
An IPP Server may be unavailable for any of the following reasons:
It is powered off.
A printer problem has caused the IPP Server to cease responding, and a restart
(reboot) is required.
The Server's IP Address has changed.
The Internet connection for the IPP Server is down.
file:///G|/CSO/T-Writer Repository/Networking/5436A Wireless Gutenberg/User Guide/English/ipp.html (5 of 6)9/14/2006 4:38:44 PM
ip_address:631/ipp/P1
