Wireless USB Print Server User Guide
Wireless USB Print Server User
Guide
Home Installation Configuration Tutorials
The Wireless USB Print Server can be used in any home or office network
environment to share a USB printer via an Ethernet network or a wireless network. By
using the USB Print Server to connect a USB printer to a wireless or Ethernet network
device, such as a wireless router or a switch, the USB printer can be shared by each
user on the network without having to tie up the resources of one computer to act as
the dedicated print server.
file:///G|/CSO/T-Writer Repository/Networking/5436A Wireless Gutenberg/User Guide/English/index.html (1 of 4)9/14/2006 4:31:22 PM
Introduction
Warranty Copyright Regulatory
Help

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Wireless USB Print Server and is the answer not in the manual?

Questions and answers

Related Manuals for US Robotics Wireless USB Print Server

Summary of Contents for US Robotics Wireless USB Print Server

  • Page 1 Introduction Warranty Copyright Regulatory The Wireless USB Print Server can be used in any home or office network environment to share a USB printer via an Ethernet network or a wireless network. By using the USB Print Server to connect a USB printer to a wireless or Ethernet network...

  • Page 2: System Requirements

    Wireless USB Print Server User Guide System Requirements A computer with an Ethernet internet connection The Installation CD-ROM that came with your printer An HTML 4.01-compliant Web Browser (such as Internet Explorer 5.5 or later or Netscape 8.0 or later) with JavaScript enabled...
  • Page 3 Wireless USB Print Server User Guide Back Item Function Restores your print server to the factory default setting, or prints a test page. To restore your print server to the factory default settings: 1. Unplug the power adapter from the print server.

  • Page 4: Warranty

    Wireless USB Print Server User Guide Wireless USB Print Server User Guide Home Installation Configuration Tutorials Help Introduction Warranty Copyright Regulatory U.S. Robotics Corporation Two (2) Year Limited Warranty 1.0 GENERAL TERMS: 1.1 This Limited Warranty is extended only to the original end-user purchaser (CUSTOMER) and is not transferable.
  • Page 5 Wireless USB Print Server User Guide 1.7 U.S. ROBOTICS warrants any replacement product or part for NINETY (90) DAYS from the date the product or part is shipped to Customer. 1.8 U.S. ROBOTICS makes no warranty or representation that this product will meet CUSTOMER requirements or work in combination with any hardware or software products provided by third parties.
  • Page 6 Wireless USB Print Server User Guide authorised U.S. ROBOTICS Service Centre, please see the U.S ROBOTICS corporate Web site at: www.usr.com 3.4 CUSTOMER should have the following information / items readily available when contacting U.S. ROBOTICS Technical Support: Product Model Number...
  • Page 7 Wireless USB Print Server User Guide 4.5 Authorised CUSTOMER returns will be unpacked, visually inspected, and matched to the Product Model Number and Product Serial Number for which the RMA was authorised. The enclosed Proof of Purchase will be inspected for date of purchase and place of purchase.
  • Page 8 Wireless USB Print Server User Guide damage cause by moisture, corrosive environments, high voltage surges, shipping, abnormal working conditions; or the use of the product outside the borders of the country or territory intended for use (As indicated by the Product Model Number and any local telecommunication approval stickers affixed to the product).
  • Page 9 Wireless USB Print Server User Guide This Limited Warranty shall be governed by the laws of the State of Illinois, U.S.A. excluding its conflicts of laws principles and excluding the United Nations Convention on Contracts for the International Sale of Goods.

  • Page 10: Copyright Information

    Wireless USB Print Server User Guide Wireless USB Print Server User Guide Home Installation Configuration Tutorials Help Introduction Warranty Copyright Regulatory Copyright Information U.S. Robotics Corporation 935 National Parkway Schaumburg, Illinois 60173-5157 No part of this documentation may be reproduced in any form or by any means or used to make any derivative work (such as a translation, transformation, or adaptation) without written permission from U.S.
  • Page 11 Wireless USB Print Server User Guide in, or delivered to you in conjunction with, this Quick Installation Guide. Copyright © 2006 U.S. Robotics Corporation. All rights reserved. U.S. Robotics and the U.S. Robotics logo are registered trademarks of U.S. Robotics Corporation. Other product names are for identification purposes only and may be trademarks of their respective companies.

  • Page 12: Regulatory Information

    Wireless USB Print Server User Guide Wireless USB Print Server User Guide Home Installation Configuration Tutorials Help Introduction Warranty Copyright Regulatory Regulatory Information Manufacturer’s Declaration of Conformity U.S. Robotics Corporation 935 National Parkway Schaumburg, IL 60173 U.S.A. declares that this product conforms to the FCC’s specifications:...

  • Page 13: Radio And Television Interference

    Wireless USB Print Server User Guide This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20 cm between the radiator and your body. Radio and Television Interference: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 14: Declaration Of Conformity

    We, U.S. Robotics Corporation of 935 National Parkway, Schaumburg, Illinois, 60173- 5157 USA, declare under our sole responsibility that the products, U.S. Robotics Wireless USB Print Server, Models 5436 and 5436A, to which this declaration relates, are in conformity with the following standards and/or other normative documents.
  • Page 15 Wireless USB Print Server User Guide EN300 328 EN301 489-1 EN301 489-17 EN60950 EN61000-3-2 EN61000-3-3 EN50392 We, U.S. Robotics Corporation, hereby declare the above named product is in compliance and conformity with the essential requirements and other relevant provisions of Directive 1999/5/EC.

  • Page 16: Operating Channels

    Wireless USB Print Server User Guide In Guyana and Reunion Islands, outdoor use is forbidden within 2400MHz – 2420MHz frequency band Regulatory Channel Frequency Frequency Channel FCC Canada ETSI (MHz) 2412 2417 2422 2427 2432 2437 2442 2447 2452 2457...
  • Page 17 Wireless USB Print Server User Guide electromagnetic radiation. This equipment should be installed and operated with minimum distance 20 cm between the radiator and your body. This wireless device is a transmitter/receiver and has been designed and manufactured to comply with the...
  • Page 18 Installation Netware Installation Windows Server Installation Step One: Connect the Wireless USB Print Server Note: The Wireless USB Print Server must be connected using an Ethernet cable for the initial configuration. After the initial configuration, you can establish a wireless connection to the network.
  • Page 19 North Europe America 5. Connect the included power adapter to the POWER port on the Wireless USB Print Server and plug the power adapter into a standard power outlet. Step Two: Configure the Wireless USB Print Server 1. Verify you are logged on to your computer as an administrator. You must be logged on as an administrator to ensure the software will be properly installed.
  • Page 20 Wireless USB Print Server User Guide 3. The Wireless USB Print Server will be shown in the list. Select the print server in the list and click Next. If it does not appear in the list, check your physical connections and click Refresh.
  • Page 21 Wireless USB Print Server User Guide click Next. 5. If you have connected the Wireless USB Print Server to a network device that has DHCP capabilities, you can select Obtain IP Address automatically. If your network device does not have DHCP capabilities, you can select Fixed IP Address and add the IP address information.
  • Page 22 Wireless USB Print Server User Guide 6. Next you can select the Region or Domain where you will be using the Wireless USB Print Server. 7. You can then select your Network Type as either Infrastructure or Ad Hoc, depending on if you are using a wireless router or access point or not in your wireless network.
  • Page 23 Wireless USB Print Server User Guide Note: The Wireless USB Print Server is initially set in Infrastructure mode, which is used to connect to an wireless router or access point. If you will be establishing a connection to other wireless clients without using a wireless router or access point, select Ad-hoc as the Network type.
  • Page 24 Wireless USB Print Server User Guide Note: The only security that the print server supports is WEP or WPA-PSK. You may need to modify the security settings of your wireless network accordingly. A. If you select WEP, you will need to select either Open System or Shared Key for your Authentication and then click Next.
  • Page 25 Wireless USB Print Server User Guide B. You will then need to select your WEP Key Length, either 64 bit Hex, 64 bits ASCII, 12 bits Hex, or 128 bits ASCII. Click Next. file:///G|/CSO/T-Writer Repository/Networking/5436A Wireless Gutenberg/User Guide/English/install.html (8 of 17)9/14/2006 4:35:10 PM...
  • Page 26 Wireless USB Print Server User Guide C. You will then need to enter your Key and select the Default Key number. Click Next when finished. ASCII 64-bit 10 characters 5 characters 128-bit 26 characters 13 characters WEP Key: 64 bits (ASCII): WEP Key: 64 bits (Hex): file:///G|/CSO/T-Writer Repository/Networking/5436A Wireless Gutenberg/User Guide/English/install.html (9 of 17)9/14/2006 4:35:10 PM...
  • Page 27 Wireless USB Print Server User Guide WEP Key: 128 bits (ASCII): file:///G|/CSO/T-Writer Repository/Networking/5436A Wireless Gutenberg/User Guide/English/install.html (10 of 17)9/14/2006 4:35:10 PM...
  • Page 28 Wireless USB Print Server User Guide WEP Key: 128 bits (Hex): D. If you select WPA-PSK, you will need to enter the WPA Key on the next screen. This Key should match what you already have in your wireless network.
  • Page 29 Wireless USB Print Server User Guide 8. After selecting your Security type and entering any necessary information, your initial configuration is complete and you should click Finish. 9. You will then be prompted to install the PTP (Peer-to-Peer) driver. Click Yes and follow the on-...
  • Page 30 Wireless USB Print Server User Guide screen instructions. 10. When that is completed, make sure the Configure Print Driver now checkbox is selected and click Finish. 11. Click OK in the Information screen that appears. It may be necessary to minimize the Print Server Utility screen in order to see the Information screen.
  • Page 31 Wireless USB Print Server User Guide If you do not see the printer, click Refresh until the port name appears. 13. Click OK on the message that appears. 14. Select the printer from the Existing Printers list. file:///G|/CSO/T-Writer Repository/Networking/5436A Wireless Gutenberg/User Guide/English/install.html (14 of 17)9/14/2006 4:35:10 PM...
  • Page 32 Wireless USB Print Server User Guide If the printer doesn’t appear, click Add New Printer and follow the onscreen instructions. 15. Click Connect. If you do not see an asterisk next to the port name in the Printer Port Setup screen, click Refresh.
  • Page 33 Step Four: Setup the Print Server for Wireless Access You can now access the wireless functions of the Wireless USB Print Server. 1. Disconnect the Ethernet cable and the power adapter from the Wireless USB Print Server. file:///G|/CSO/T-Writer Repository/Networking/5436A Wireless Gutenberg/User Guide/English/install.html (16 of 17)9/14/2006 4:35:10 PM...
  • Page 34 Congratulations! You have successfully completed the installation procedure. Please register your Wireless USB Print Server at www.usr.com/productreg. To print out a diagnostic page with the setting information for the Wireless USB Print Server, press the RESET button once. © 2004-2006 U.S. Robotics Corporation.
  • Page 35 Wireless USB Print Server Installation Client Installation Macintosh Installation Unix Installation Netware Installation Windows Server Installation Before performing client configuration, the Wireless USB Print Server must be installed on your LAN, and configured as described in the Wireless USB Print Server Installation section.
  • Page 36 Wireless USB Print Server User Guide 3. You will need to select the type of user that this computer will be: User, Administrator, Custom, or Client. file:///G|/CSO/T-Writer Repository/Networking/5436A Wireless Gutenberg/User Guide/English/install_client.html (2 of 16)9/14/2006 4:35:27 PM...
  • Page 37 User User is the most common option that the majority of network clients will want to choose. This should be selected if the Wireless USB Print Server has already been configured and you just need printing capabilities on this computer.
  • Page 38 Wireless USB Print Server User Guide 3. Follow the on-screen instructions to select the location and install the PTP (Peer- to-Peer) driver. 4. When that is completed, make sure the Configure Print Driver now checkbox is selected and click Finish.
  • Page 39 Wireless USB Print Server User Guide 6. In the Printer Port Setup, select the port and click Next. If you do not see the printer, click Refresh until the port name appears. 7. Click OK on the message that appears.
  • Page 40 Wireless USB Print Server User Guide 8. Select the printer from the Existing Printers list. file:///G|/CSO/T-Writer Repository/Networking/5436A Wireless Gutenberg/User Guide/English/install_client.html (6 of 16)9/14/2006 4:35:27 PM...
  • Page 41 Wireless USB Print Server User Guide If the printer doesn’t appear, click Add New Printer and follow the onscreen instructions. 9. Click Connect. If you do not see an asterisk next to the port name in the Printer Port Setup screen, click Refresh.
  • Page 42 Wireless USB Print Server User Guide 11. Repeat this step on each computer. You will now be able to use your USB printer from this computer. To validate your setup, you can print a test page. Administrator Administrator will install the necessary tools for initial configuration, as well as the BiAdmin Management Utility.
  • Page 43 Wireless USB Print Server User Guide 3. Click Next and then Finish. file:///G|/CSO/T-Writer Repository/Networking/5436A Wireless Gutenberg/User Guide/English/install_client.html (9 of 16)9/14/2006 4:35:27 PM...
  • Page 44 Wireless USB Print Server User Guide This will add the BiAdmin Management Utility to your computer. Click the icon on your desktop or the program menu link to launch the BiAdmin Management Utility. You can use the BiAdmin Management Utility to configure the settings of the Wireless USB Print Server.
  • Page 45 Wireless USB Print Server User Guide 3. Click Next. file:///G|/CSO/T-Writer Repository/Networking/5436A Wireless Gutenberg/User Guide/English/install_client.html (11 of 16)9/14/2006 4:35:27 PM...
  • Page 46 Wireless USB Print Server User Guide 4. Click Next and then Finish. file:///G|/CSO/T-Writer Repository/Networking/5436A Wireless Gutenberg/User Guide/English/install_client.html (12 of 16)9/14/2006 4:35:27 PM...
  • Page 47 Wireless USB Print Server User Guide The selected options are now installed. IPP Client IPP (Internet Printing Protocol) Client is required if you want to print to any servers, either on the local network or accessed remotely over the Internet. This should only be chosen by more advanced network clients.
  • Page 48 Wireless USB Print Server User Guide 3. Click Next. file:///G|/CSO/T-Writer Repository/Networking/5436A Wireless Gutenberg/User Guide/English/install_client.html (14 of 16)9/14/2006 4:35:27 PM...
  • Page 49 Wireless USB Print Server User Guide 4. Click Next and then Finish. file:///G|/CSO/T-Writer Repository/Networking/5436A Wireless Gutenberg/User Guide/English/install_client.html (15 of 16)9/14/2006 4:35:27 PM...
  • Page 50 Wireless USB Print Server User Guide Installing using IPP_CLIENT.EXE 1. Run this program to unzip the included files. 2. The IPP Setup program will then run. 3. Follow the prompts to complete the installation. © 2004-2006 U.S. Robotics Corporation. file:///G|/CSO/T-Writer Repository/Networking/5436A Wireless Gutenberg/User Guide/English/install_client.html (16 of 16)9/14/2006 4:35:27 PM...
  • Page 51 Unix Installation Netware Installation Windows Server Installation Macintosh (AppleTalk) The Wireless USB Print Server supports AppleTalk (EtherTalk), PAP, ATP, NBP, ZIP and DDP protocols, enabling Macintosh computers on the network to view and use the Wireless USB Print Server as a regular AppleTalk printer. Normally, no special configuration is required.
  • Page 52 Management Utility to configure the Wireless USB Print Server. Macintosh OS X If using LPR printing, you need to ensure the Wireless USB Print Server has a valid IP address before configuring your Mac as follows. LPR printing Setup 1. Select the Printer List icon.
  • Page 53 Wireless USB Print Server User Guide 2. Click Add Printer. 3. Select LPR Printers Using IP. 4. Enter the IP address of the Print Server in the LPR Printer's Address field, and enter the Queue Name (L1 for port 1, L2 for port 2 if the Wireless USB Print Server has 2 printer ports.).
  • Page 54 Wireless USB Print Server User Guide © 2004-2006 U.S. Robotics Corporation. file:///G|/CSO/T-Writer Repository/Networking/5436A Wireless Gutenberg/User Guide/English/install_mac.htm (4 of 4)9/14/2006 4:35:45 PM...
  • Page 55 Your Wireless USB Print Server supports the LPD Unix printing method, which is supported by all common Unix systems. You must configure both the Wireless USB Print Server and your Unix system, as described in the following sections. Wireless USB Print Server IP Address Configuration Because it supports dynamic IP Address allocation using DHCP or BOOTP, the Wireless USB Print Server ships with an IP Address of 0.0.0.0.
  • Page 56 Server. 00:c0:02:xx:xx:xx is the hardware address of the Wireless USB Print Server. Example: arp -s 192.168.0.21 00:c0:02:12:34:56 You should then assign this IP address to the Wireless USB Print Server using your Web Browser. Launch the Web User Interface and go to the TCP/IP section. Select Fixed IP Address and then enter the appropriate information.
  • Page 57 Type of print spooler on remote server: Use default value. (AIX Version xxx) 6. Ensure that the logical printers are configured in the Wireless USB Print Server. 7. Print using the following command: lp -d printer_queue file_name Where: printer_queue is one of the entries used in Name of queue to add.
  • Page 58 Commands In the sample commands shown, printer_name is the name of the Print Queue serviced by the Wireless USB Print Server, and Spooler_directory is the name of the directory, which is used to spool the print jobs. Stop Print Services: /usr/lib/lpshut...
  • Page 59 Wireless USB Print Server User Guide Note: The entry is really one line, but can be entered as shown. Use a TAB character where shown. Printer_name|Remote_Printer_Alias:\ [Tab] :lp=:\ [Tab] :rm=PS_NAME:\ [Tab] :rp=Logical_Printer_name:\ [Tab] :sd=Spooler_directory:\ [Tab] :mx#0: Example: Marketing|RP1_PS123456:\ [Tab] :lp=:\...
  • Page 60 Commands In the sample commands shown, printer_name is the Print Queue serviced by the logical printer on the Wireless USB Print Server, and Spooler_dir is the name of the directory, which is used to spool the print jobs. Create a spooling directory: mkdir /usr/spool/Spooler_dir...
  • Page 61 Printer_name is the Print Queue name used to store jobs for the corresponding logical printer. PS_NAME is the Wireless USB Print Server name defined in /etc/hosts. Logical_Printer_name is the logical printer name on the Wireless USB Print Server. (e.g. L1) Spooler_directory is the directory you created.
  • Page 62 Wireless USB Print Server User Guide For LPD printing instructions, refer to your UNIX manual. The following example is for a BSD system: lpr -P printer_name filename Where: printer_name is the name of the Print Queue defined on the Unix host.
  • Page 63 Wireless USB Print Server User Guide Wireless USB Print Server User Guide Home Installation Configuration Tutorials Help Wireless USB Print Server Installation Client Installation Macintosh Installation Unix Installation Netware Installation Windows Server Installation Netware Overview The Print Server must be configured as a valid device on your TCP/IP network. This printing method uses LPR over TCP/IP, not the Netware protocol.
  • Page 64 Wireless USB Print Server User Guide 4. Select NDPS Manager as the object to create. The Create NDPS Manager Object window shown below will appear. 5. Type a name in the NDPS Manager Name.(e.g. SerMGR, as shown above) 6. Browse the Resident Server and select where you want the NDPS Manager object to be assigned.
  • Page 65 Wireless USB Print Server User Guide 1. Start the NDPS Manager object you will be using to control the Printer Agent. 2. At the Identification page, click Printer Agent List. 3. Click New to see the Create Printer Agent window, as shown below.
  • Page 66 Wireless USB Print Server User Guide 10. In the Host address IP field, enter the IP Address previously assigned to the Print Server device. 11. In the Printer Name field, enter the Logical Port name on the Print Server. (L1 for Port 1, L2 for port 2).

  • Page 67: Windows Server

    Wireless USB Print Server User Guide Wireless USB Print Server User Guide Home Installation Configuration Tutorials Help Wireless USB Print Server Installation Client Installation Macintosh Installation Unix Installation Netware Installation Windows Server Installation Windows Server Windows NT4.0 Server If using Windows NT 4.0, Microsoft TCP/IP Printing Support must be installed.
  • Page 68 (e.g. L1) as previously configured on the Wireless USB Print Server. By default, L1 is port 1, and L2 is port 2 if the Wireless USB Print Server has 2 printer ports. 7. Click OK. When returned to the Printer Ports window, select Close and then install your printer driver as usual.
  • Page 69 1. Launch the Add Printer Wizard, select Network Printer, then click Next to browse for the Wireless USB Print Server. 2. Locate and double-click the Wireless USB Print Server, select the desired port, and click Next. A message like the following will be displayed: 3.
  • Page 70 2. In the location or address line, type the IP address of the Wireless USB Print Server and press ENTER. IP Address Example: 192.168.x.x If you do not know the IP address of the Wireless USB Print Server, open the BiAdmin Management Utility. The IP address, along with other information about the print server, is displayed on the first screen of the utility.
  • Page 71 Wireless USB Print Server User Guide Wireless Security Apple Talk NetBEUI TCP/IP © 2004-2006 U.S. Robotics Corporation. file:///G|/CSO/T-Writer Repository/Networking/5436A Wireless Gutenberg/User Guide/English/wui.html (2 of 2)9/14/2006 4:37:39 PM...
  • Page 72 Wireless USB Print Server User Guide Wireless USB Print Server User Guide Home Installation Configuration Tutorials Help Web User Interface Management Utility The BiAdmin Management Utility can be used to configure the settings of the Wireless USB Print Server. This utility is for advanced users or for users on a network with multiple Wireless USB Print Servers.
  • Page 73 Wireless USB Print Server User Guide 3. Select Custom. file:///G|/CSO/T-Writer Repository/Networking/5436A Wireless Gutenberg/User Guide/English/management.html (2 of 7)9/14/2006 4:38:13 PM...
  • Page 74 Wireless USB Print Server User Guide 4. Verify sure BiAdmin is selected. file:///G|/CSO/T-Writer Repository/Networking/5436A Wireless Gutenberg/User Guide/English/management.html (3 of 7)9/14/2006 4:38:13 PM...
  • Page 75 Wireless USB Print Server User Guide 4. Follow the on-screen instructions to complete the installation. Using the BiAdmin Management Utility You can launch the BiAdmin Management Utility by using the link in the Programs menu. When it is launched, the BiAdmin Management Utility will search your network for all the Wireless USB Print Servers that are attached and running.
  • Page 76 Wireless USB Print Server User Guide On the left side of the screen, you will see each Wireless USB Print Server that is attached to the network. If you select a Wireless USB Print Server, you will see the settings information on the right side of the screen.
  • Page 77 Set to Default on that particular screen. Attached Remote: This is used to connect to a Wireless USB Print Server that is located on another LAN segment. You need to enter IP address of the remote Wireless USB Print Serve and click Set.
  • Page 78 Wireless USB Print Server User Guide Once a Wireless USB Print Server has been selected, the icons can be used. The icons provide status information as well as access to the selected Wireless USB Print Server settings. If an icon is grayed out, that option or protocol is unavailable.

  • Page 79: Printing Methods

    The Wireless USB Print Server supports a number of printing methods: Peer-to-peer Printing means that the print jobs are stored (queued) on your computer, and sent directly to the Wireless USB Print Server when it is available. Windows SMB Printing is a Microsoft standard for using a Network Printer.
  • Page 80 Wireless USB Print Server User Guide Printing. If your LAN has Network Servers (e.g. Windows NT, Windows 2000 Server), use the method advised by your Network Administrator. The Wireless USB Print Server can print via a queue located on a Network server, if desired.
  • Page 81 Windows Peer-to-peer Printing With this printing method, print jobs are stored (queued) on your computer and then sent to the Wireless USB Print Server when it is available. Windows 2000 and XP require no additional software. For other versions of Windows, the supplied PTP (Peer-to-Peer) Printer Port software must be installed on each computer.
  • Page 82 Wireless USB Print Server User Guide 4. On the Add Standard TCP/IP Printer Port screen above, enter the IP Address of the Print Server in the Printer Name or IP Address field and then click Next. file:///G|/CSO/T-Writer Repository/Networking/5436A Wireless Gutenberg/User Guide/English/printing.html (4 of 14)9/14/2006 4:38:29 PM...
  • Page 83 Wireless USB Print Server User Guide 5. On this screen, select Custom and click Settings. 6. On the Port Settings screen, select LPR in the Protocol section. Enter a Queue name (L1 for the USB Port). Ensure the LPR Byte Counting Enabled setting is Enabled.
  • Page 84 7. Follow the prompts to complete the Wizard. Windows 9x/ME Setup Before performing the following procedure, the Wireless USB Print Server must be installed on your LAN, and configured as described in Installation. Both the Wireless USB Print Server and the attached printer should be powered ON.
  • Page 85 NetBEUI protocol. Then try again. 2. Select the desired port on a Wireless USB Print Server and then click Next. A message will inform you if the port has been created successfully. file:///G|/CSO/T-Writer Repository/Networking/5436A Wireless Gutenberg/User Guide/English/printing.html (7 of 14)9/14/2006 4:38:29 PM...
  • Page 86 Wireless USB Print Server User Guide If you see the following error message, either install Internet Explorer 4 or later or go to Troubleshooting. 3. The printer port will be created, then a screen similar to the one below will be displayed.
  • Page 87 2. Locate the and click Delete Port. This button is on the Details or Ports tab, depending on your version of Windows. If the Wireless USB Print Server's IP Address is changed and you can no longer print, delete the port (see procedure above) and re-install it.

  • Page 88: Windows Smb Printing

    Wireless USB Print Server User Guide Items shown on this screen are as follows: Port: If desired, click Browse to select a different Wireless USB Print Server. If the selected device has multiple ports, the Select Device Port button can be used to select the port.
  • Page 89 If it is in a different workgroup, double-click Entire Network, then double-click the appropriate Workgroup to open it. 4. Double-click the Wireless USB Print Server icon to view a Printer icon for each printer port. The Comment field may indicate what type of printer is connected to the port.
  • Page 90 7. Select the Printer Manufacturer and Model to match the printer connected to this port on the Wireless USB Print Server and complete the Wizard. 8. This printer will now appear in your Printers folder and can be used like any other printer.
  • Page 91 Wireless USB Print Server User Guide Windows XP: 4. Browse the network, and locate the Server and Printer (or Print Queue) which your Network Administrator advised you to use. 5. Click OK and then Next. 6. Select the correct printer Manufacturer and Model, as advised by your Network Administrator, and click Next.
  • Page 92 Wireless USB Print Server User Guide © 2004-2006 U.S. Robotics Corporation. file:///G|/CSO/T-Writer Repository/Networking/5436A Wireless Gutenberg/User Guide/English/printing.html (14 of 14)9/14/2006 4:38:29 PM...
  • Page 93 Wireless USB Print Server User Guide Wireless USB Print Server User Guide Home Installation Configuration Tutorials Help Printing Methods IPP (Internet Printing Protocol) IPP (Internet Printing Protocol) is a standards-based system to allow remote printing from a computer to any accessible printer. Normally, the printer will be attached to a computer or other device which functions as an IPP Server.
  • Page 94 Wireless USB Print Server User Guide IPP Client Configuration 1. Run the Add IPP Port program entry created by the installation. A screen like the following will be displayed. 2. If Internet access from your location is via a Proxy Server, select Access IPP Server via Proxy Server and enter the details of your Proxy Server.
  • Page 95 Wireless USB Print Server User Guide 6. Perform one of the following options: Select an existing printer to use the new port and click OK. Click Add New Printer to create a new printer to use the IPP port. This will start the Add Printer wizard.
  • Page 96 Wireless USB Print Server User Guide There are 2 settings - Retry Interval and Retry Count - which can be adjusted if you have problems connecting to the IPP Server. Retry Interval sets the time interval (in seconds) between connection attempts.
  • Page 97 Wireless USB Print Server User Guide 3. Select Connect to a printer on the Internet or on your Intranet and enter the URL of the IPP Server as follows, where ip_address represents the IP Address of the IPP Server and 631 is the port number.
  • Page 98 Wireless USB Print Server User Guide Network congestion causes the connection attempt to time out. If using the supplied IPP Client software, there are 2 settings - Retry Interval and Retry Count - which can be adjusted if you have problems connecting to the IPP Server.

  • Page 99: Troubleshooting

    Wireless USB Print Server User Guide Wireless USB Print Server User Guide Home Installation Configuration Tutorials Help Troubleshooting Support Basic Troubleshooting Procedure This procedure addresses a number of symptoms that you might experience with your print server: 1. Verify the physical cable connections between the print server, the printer, your router, and your power outlet.
  • Page 100 I am unable to print via a wireless connection or the Wireless Print Server is not connecting to my wireless network. I created a new wireless network and the Wireless USB Print Server is not connecting to it. I have installed my multi-function printer, but my fax and scanner capabilities do not work.
  • Page 101 Unix The Wireless USB Print Server is not recognized. I don't know t he IP Address of the Wireless USB Print Server and it is being moved to a new network environment. © 2004-2006 U.S. Robotics Corporation. file:///G|/CSO/T-Writer Repository/Networking/5436A Wireless Gutenberg/User Guide/English/troubleshooting.html (3 of 3)9/14/2006 4:38:56 PM...
  • Page 102 Wireless USB Print Server User Guide Wireless USB Print Server User Guide Home Installation Configuration Tutorials Help Troubleshooting Support Support 1. Know your model and serial number. Your model number is 5436A. You can find your serial number on the side of the package and on the bottom of the router.
  • Page 103 Wireless USB Print Server User Guide www.usr.com/emailsupport/ea Denmark 38323011 www.usr.com/emailsupport/ea Finland 08 0091 3100 www.usr.com/emailsupport/fr France 0825 070 693 www.usr.com/emailsupport/de Germany 0180 567 1548 www.usr.com/emailsupport/gr Greece www.usr.com/emailsupport/hu Hungary 0180 567 1548 www.usr.com/emailsupport/uk Ireland 1890 252 130 www.usr.com/emailsupport/it Italy 800 979 266 www.usr.com/emailsupport/be...
