US Robotics Wireless USB Print Server User Manual page 59

Wireless USB Print Server User Guide
Note: The entry is really one line, but can be entered as shown. Use a TAB
character where shown.
Printer_name|Remote_Printer_Alias:\
[Tab] :lp=:\
[Tab] :rm=PS_NAME:\
[Tab] :rp=Logical_Printer_name:\
[Tab] :sd=Spooler_directory:\
[Tab] :mx#0:
Example:
Marketing|RP1_PS123456:\
[Tab] :lp=:\
[Tab] :rm=PS_Rm203:\
[Tab] :rp=L1:\
[Tab] :sd=/usr/spool/Marketing:\
[Tab] :mx#0:
Repeat this process for each Logical Printer/Print Queue combination that you wish to
create.
LPD on Linux
If using the command line, the procedure is the same as for System V. (above)
On recent Linux distributions, you can use the graphical X-windows interface instead
of the command line. The procedure is described below, but may vary according to
your version of Linux.
1. Start your X-windows shell.
2. Select Control Panel and then Printer Configuration.
3. Select Add. For the printer type, select Remote Unix (lpd) Queue.
4. Use the following data to complete the resulting dialog:
Name: Enter a name for this printer
