Wireless USB Print Server User Guide
Main: From this menu, you can select the following:
Device Status
Printer Status
Configure
Upgrade
Refresh
Exit
InitDevice: From this menu, you can select and perform the following:
Reset Device: This will cause the Wireless USB Print Server to reboot. To
reboot the print server, click Yes. This should be done after making any
configuration changes or if the Wireless USB Print Server stops responding.
Restore to Factory Default: To restore all of the Wireless USB Print Server
values to the factory default settings, click Yes. To restore the settings only for
the current screen in the management utility, click Set to Default on that
particular screen.
Attached Remote: This is used to connect to a Wireless USB Print Server that
is located on another LAN segment. You need to enter IP address of the remote
Wireless USB Print Serve and click Set. If your LAN does not have a router, this
option is not applicable.
Connected Protocol: This option allows you to designate which LAN protocol is
used for communication between the selected Wireless USB Print Server and
this application. You should select only one protocol.
Diagnostic: From this menu, you can select Print Test Page and then select the
printer that should print the page. This will print out a test page which contains the
configuration settings of the Wireless USB Print Server.
Help: From this menu, you can select Help Topics or the About BiAdmin for more
information on the BiAdmin Management utility.
Status Icons
