US Robotics Wireless USB Print Server User Manual page 56

Wireless USB Print Server User Guide
arp -s IP_Address 00:c0:02:xx:xx:xx
Where:
IP_Address is the IP Address you wish to assign to the Wireless USB Print
Server.
00:c0:02:xx:xx:xx is the hardware address of the Wireless USB Print Server.
Example: arp -s 192.168.0.21 00:c0:02:12:34:56
You should then assign this IP address to the Wireless USB Print Server using your
Web Browser. Launch the
Fixed IP Address and then enter the appropriate information.
Note: The hardware address of the Wireless USB Print Server is shown on a
sticker on the base of the device.
Other Wireless USB Print Server Configuration
The recommended method to configure the Wireless USB Print Server is to use the
Web User Interface.
Ensure that the TCP/IP settings are correct for your network.
The logical printers (e.g. L1) must be configured correctly to match your
system.
LPD Configuration
Configuration for
LPD on BSD are described below.
LPD on IBM AIX 4.15
Before proceeding, ensure that the Wireless USB Print Server has been assigned an IP
file:///G|/CSO/T-Writer Repository/Networking/5436A Wireless Gutenberg/User Guide/English/install_unix.htm (2 of 8)9/14/2006 4:36:16 PM
Web User Interface
LPD on IBM AIX
and go to the TCP/IP section. Select
4.15, LPD on System V, LPD on Linux, and
