2-Color Display
Reversible display mode
When the product is used upside down, the orientation
of the display can be rotated to make it easier to read.
OUT
OUT
Piping variations
(Straight)
ø6
One-touch fitting:
Mounting
variations
Analog free span function
The analog span point (5 V
(10 V), 20 mA) can be
changed within the rated
pressure range of 10 to
105% with respect to the
displayed value.
Application example
When it is required to output 5 V
from the flow switch at 75 L/min,
using a sensor that outputs 1 to
5 V at 1 to 100 L/min.
Selectable analog output function
1 to 5 V or 0 to 10 V can be selected.
1
Digital Flow Switch
IN
Reversible display
mode setting
IN
ø8
One-touch fitting:
Bracket
Analog output
Changeable range
5 V (10 V)
20 mA
At the time of shipment
1 V
4 mA
0% 10%
Analog output
Adjustment point: 75 L/min , 100 L/min
5 V
Change
At the time of shipment
1 V
1 L/min
PF2M7
Series
Flow adjustment
valve is integrated.
Space-saving design
Reduced piping
labor
Display OFF mode
Unnecessary LEDs can be turned off and checked
only when necessary. Can be used as a remote
sensor
DIN rail
Display
100% 105%
Display
75 L/min 100 L/min
Flow adjustment
valve
Panel mount P
Delay time setting
Can be set between 0 and 60 s
The delay time can be set according to the
application.
Grease-free
Functions
p. 16
Output operation Key lock
Forced output Reset to the default settings
Analog free span Delay time setting
Display color Error display
Selection of display OFF mode Setting of security code
Selectable analog output Display mode
Reference condition Display with zero cut-off setting
Peak/Bottom value display Accumulated value hold
Reversible display Simple setting
Digital filter setting Zero clear
