Research and Production Enterprise "DISC SYSTEMS" LTD
EDRPOU 16303375, a/c No.260075014037759
at PJSC "UKREXIMBANK" in c. Kyiv
MFO 380333, TIN 163033726585
03061, Ukraine, c. Kyiv, 95-S Otradny ave., Telephone +38044 507 02 07. Fax +38044 507 02 02. www.bitrek.com.ua, sales@bitrek.com.ua
Vehicles tracking device
BI-910 TREK
Operating Manual
Version 2019.09.1
www.bitrek.com.ua
sales@bitrek.com.ua
+380 44 507 02 07

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BI-910 TREK and is the answer not in the manual?

Questions and answers

Related Manuals for BITREK BI-910 TREK

Summary of Contents for BITREK BI-910 TREK

  • Page 1 EDRPOU 16303375, a/c No.260075014037759 at PJSC "UKREXIMBANK" in c. Kyiv MFO 380333, TIN 163033726585 03061, Ukraine, c. Kyiv, 95-S Otradny ave., Telephone +38044 507 02 07. Fax +38044 507 02 02. www.bitrek.com.ua, sales@bitrek.com.ua Vehicles tracking device BI-910 TREK Operating Manual Version 2019.09.1...

  • Page 2: Table Of Contents

    Configuring the Device for Operation with Fuel Meter RS-485 ........ 31 Use of Backup Server ..................32 Configuring Engine Lock ................... 32 Addendum 1. Device parameters ............... 34 Addendum 2. List of I/O components ..............47 www.bitrek.com.ua sales@bitrek.com.ua +380 44 507 02 07...

  • Page 3: Introduction

    Device Intended Use of the Device Tracking device BI-910 TREK is used for navigation tasks, remote control and monitoring of a vehicle or other remote object. The tracking device is intended for installation to any mobile or remote stationary object in order to: ...

  • Page 4: Principle Of Operation

    GPS and GSM antennae External Navigation system types GPS or GPS/GLONASS RS-485, 1Wire, CAN Auxiliary digital protocol (FMS) Motion sensor Acceleration meter Secure power supply input Number of SIM cards Number of 0-active discrete inputs www.bitrek.com.ua sales@bitrek.com.ua +380 44 507 02 07...

  • Page 5: Tracking Device Design

    125 х 95 х 33 Weight 200 g Body IP 65 (plastic РА 6) Connection (cable) IP 68 Tracking device design Fig. 1. Appearance and Dimensions of Tracking Device BI-910 TREK. (General view) www.bitrek.com.ua sales@bitrek.com.ua +380 44 507 02 07...

  • Page 6: Scope Of Delivery

    Fig. 2. Appearance and Dimensions of Tracking Device BI-910 TREK. (Rear view) Scope of Delivery 1. Tracking Device BI-910 TREK - 1 pc. 2. GPS antenna – 1 pc. 3. GSM antenna – 1 pc. 4. Connection cable - 1 pc.

  • Page 7: Sockets For Power Supply, Antennas, And Periphery Devices

    Figure 3. Fig. 3. Appearance and Antennae Connectors Legends on Tracking Device BI-910 TREK To connect to the power supply socket, sensors and actuators, IP 68 connector socket is used. Location of power supply socket is shown in Figure 4.

  • Page 8: Connection Of The Power Supply, Discrete And Analog Sensors, As Well As Extra Devices

    Fig. 4. Location of the Socket and Numbers of Pins Connection of the Power Supply, Discrete and Analog Sensors, as well as Extra Devices Fig. 5. BI-910 TREK Contact Pins www.bitrek.com.ua sales@bitrek.com.ua +380 44 507 02 07...
  • Page 9 Speaker output "-" Blue DAT_high 1 Input 1-active discrete input Gray An_in 2 Input Analog input No.2 Green DAT_low 3 Input 0-active discrete input Green/Black Input/Output "B" signal RS-485 Black Power Ground (earth) www.bitrek.com.ua sales@bitrek.com.ua +380 44 507 02 07...

  • Page 10: Installation And Commissioning

    Voltage on the discrete inputs and outputs should not exceed 30 V. Voltage on the analog inputs should not exceed 30 V. Device input voltage should not exceed 36 V. Otherwise, the device can be damaged. www.bitrek.com.ua sales@bitrek.com.ua +380 44 507 02 07...

  • Page 11: Connection To A Computer

    Fig. 6. BI-910 TREK Connection Diagram A terminal program can be used for data exchange with the device. Terminal configuration settings: bit rate – 115,200 bps, data bit – 8, stop bit –...

  • Page 12: List Of Sms Commands

    SMS is only limited by the maximum length of an SMS. It is also essential to observe the order of the commands, when they are sent in one SMS message. The device reads and performs the www.bitrek.com.ua sales@bitrek.com.ua +380 44 507 02 07...

  • Page 13: Configuring The Device

    If there is no authorized phone number enabled, SMS with commands will be received from any phone number. Configuring the Device The BI-910 TREK Tracking Device can be configured by one of the methods below: 1. Using a direct connection between the device and a computer.
  • Page 14 #### boot #,#,# Update of device firmware Set operating modes for setdigout ## digital outputs Out 1 and Out Disabling safety lock with the ignitionoff ignition Enabling safety lock with the ignitionon ignition www.bitrek.com.ua sales@bitrek.com.ua +380 44 507 02 07...

  • Page 15: Detailed Description Of Information Commands

    Date: 2018/4/30 Time: 12:33:45 Command of request for link with device coordinates – getmap; Example of a response: "www.biakom.com/maps/q=50.420209,30.428448,12,0" Command of request of device firmware version – getver; Example of a response: BI-910 VER 3.16.7 www.bitrek.com.ua sales@bitrek.com.ua +380 44 507 02 07...

  • Page 16: Detailed Description Of Controlling Commands

    Param ID 0242 Val: internet Detailed Description of Controlling Commands Command of complete device CPU reset – cpureset; There is no response to this command. Once the command is received, all processes of the device reset. www.bitrek.com.ua sales@bitrek.com.ua +380 44 507 02 07...
  • Page 17 PORT – Port of the server containing the update; PATH – Path to the firmware update file on the server; Example of the command: BOOT fw.bitrek.ua,80,*.bin; Where * is a version of the firmware, .bin – file format extension. Options of response to the attempted update download: BOOT: UPDATE DOWNLOAD OK –...

  • Page 18: Basic Device Configuration

    Once a mobile carrier SIM-card is inserted and power supply is connected, the device needs to be configured for transferring data to the server. When the Bitrek Configurator is used, all configuration settings will be divided into groups:  Server and GPRS ...

  • Page 19: Configuring I/O Components

    SMS with the commands. Configuring I/O Components The BI-910 TREK Tracking Device can collect, process and send data obtained from different sensors to the server. Each sensor is an I/O component and has a group consisting of 6 parameters for configuration.
  • Page 20 Parameter 2 - Upper threshold – setting the upper threshold of the I/O component; Parameter 3 - Lower threshold – setting the lower threshold of the I/O component; www.bitrek.com.ua sales@bitrek.com.ua +380 44 507 02 07...
  • Page 21 Example: Lower threshold of input voltage is set to 0 V, the upper threshold is 10 V (10000 mV). If the input voltage increases over 10 V, the event will be generated (Figure 8). www.bitrek.com.ua sales@bitrek.com.ua +380 44 507 02 07...
  • Page 22 4 - Monitoring + Going Within Range. When a Going Within Range event is generated, actual value from the sensor starts to be transmitted to the server in the monitoring mode. 5 - Monitoring + Going Beyond Range. www.bitrek.com.ua sales@bitrek.com.ua +380 44 507 02 07...

  • Page 23: Configuring Alarms

    The IDs of an I/O components by which SMS messages are sent should be configured as a trigger for outbound SMS messages. A user-defined text may be included www.bitrek.com.ua sales@bitrek.com.ua +380 44 507 02 07...

  • Page 24: Switching Between The Profiles

    0, selects SIM1 and waits for the SIM card to get up and ready as well as for the registration on the network. If the SIM-card has not been detected within a certain time, or it has been www.bitrek.com.ua sales@bitrek.com.ua +380 44 507 02 07...
  • Page 25 0 for SIM1, and profile 1 for SIM2, excluding GPRS connection parameters - APN/Usname/Uspass. These parameters are unique for each operator and have their own IDs for configuration. www.bitrek.com.ua sales@bitrek.com.ua +380 44 507 02 07...
  • Page 26 These parameters are unique for each operator and have their own IDs for configuration. If the device registers on the home network, it uses the GPRS access settings of profile 0 for SIM1, and of profile 1 for SIM2. www.bitrek.com.ua sales@bitrek.com.ua +380 44 507 02 07...

  • Page 27: Configuring Roaming Settings

    The configuration is given based on the example of dual-SIM device operation: on the home network and roaming. Nation GSM carrier SIM-card is inserted to slot for SIM1 and roaming card goes to SIM2. Profile switch is enabled: setparam 0916 1; www.bitrek.com.ua sales@bitrek.com.ua +380 44 507 02 07...
  • Page 28 0179 <GPRS password>; ATTENTION! If you specify the list of enabled operators, but do not specify APN, GPRS login, GPRS password for each of them, the device will not work in roaming. www.bitrek.com.ua sales@bitrek.com.ua +380 44 507 02 07...

  • Page 29: List Of Prohibited Operators

    List of prohibited operators The monitoring device BI-910 TREK has the ability to work with a list of prohibited operators. In addition to operating modes 0917 = 0, 1, 2, 3, which are discribed in this manual, operating modes 10, 11, 12, 13 are added.
  • Page 30 I/O component will record the readings from the meter polled the last. Connection pattern between thermometer and BI-910 TREK tracker is given in Table 7. Table 7. Connection of Thermometer to BI-910 TREK Using Parasite Power Pattern Term Tracker...

  • Page 31: Configuring The Device For Operation With Fuel Meter Rs-485

    Configuring the Device for Operation with Fuel Meter RS-485 The BI-910 TREK Tracking Device is compatible with fuel meter supporting RS-485 bus. In total, up to four fuel meters can be connected. Respective I/O component must be enabled in the configuration settings of the device.

  • Page 32: Use Of Backup Server

    Fig. 11. А & В Communication Line Connection and Configuration Diagram. Use of Backup Server The BI-910 TREK Tracking Device supports the use of a backup server (Host2 Port2). The ID=0196 parameter is used for this case and by default is set to 0.
  • Page 33 When the lock is disabled, the device will send the response: ignitionoff; ATTENTION! The ignitionon; ignitionoff; commands will be performed by the device provided that they have been received via SMS message. www.bitrek.com.ua sales@bitrek.com.ua +380 44 507 02 07...

  • Page 34: Addendum 1. Device Parameters

    Connect Try Time between 0905 none 2 byte sec. 0 - 65535 Interval connection attempts Connect Time between serial Serial 0906 none 2 byte sec. 0 - 65535 attempts to connect Interval www.bitrek.com.ua sales@bitrek.com.ua +380 44 507 02 07...
  • Page 35 Acceleration meter X- Delta X 0281 none 1 byte c.u. 1 - 256 direction deviation angle Acceleration meter Y- Delta Y 0282 none 1 byte c.u. 1 - 256 direction deviation angle www.bitrek.com.ua sales@bitrek.com.ua +380 44 507 02 07...
  • Page 36 0 or 3 - GPS Source Selecting geopositioning GPS+GLONASS; 4016 none 1 byte c.u. Select system 1 - GPS only; 2 - GLONASS only; Safety Authorized phone Phone0 0261 none String +xxxxxxxxxxxx number 0 www.bitrek.com.ua sales@bitrek.com.ua +380 44 507 02 07...
  • Page 37 0910 none String Device access password 11111 Password Enabling SIM-card SIM_PIN 0818 none 1 byte carrier's PIN-number Service Period of regular device Reboot Per 0186 none 1 byte hour 1 - 256 reboot www.bitrek.com.ua sales@bitrek.com.ua +380 44 507 02 07...
  • Page 38 0 - 14 adjustment Alarms Enabling outbound voice 0 - disabled; 1 - RingEnable 0913 none 1 byte calls enabled; ID of I/O component OutCall 0914 none 2 byte triggering outbound Trigger voice call www.bitrek.com.ua sales@bitrek.com.ua +380 44 507 02 07...
  • Page 39 Selection 0917 none 1 byte 3 - enabled selection Enable (different modes) 0020… UsipTable none string List of enabled carriers xxxxx 0059 0060… List of APNs of enabled UsAPNTable none string 0099 carriers www.bitrek.com.ua sales@bitrek.com.ua +380 44 507 02 07...
  • Page 40 1 - 20 _of_fuel below the specified one will be filtered Enabling the use of last 0 - disabled; 1 - ValidfuelLevel 0819 none 1 byte valid fuel level (filtered none enabled; and non-filtered levels) www.bitrek.com.ua sales@bitrek.com.ua +380 44 507 02 07...
  • Page 41 4 byte F factor for Kalman filter c.u. 1000000 Q factor for Kalman FactorQ 0951 none 4 byte c.u. 1000000 filter H factor for Kalman FactorH 0952 none 4 byte c.u. 1000000 filter www.bitrek.com.ua sales@bitrek.com.ua +380 44 507 02 07...
  • Page 42 GSM_Reg_ Timeout for registration 4019 none 2 byte 60 – 300 Timeout on the GSM network GPRS_Reg_ Timeout for registration 4020 none 2 byte 60 - 300 Timeout on the GPRS network www.bitrek.com.ua sales@bitrek.com.ua +380 44 507 02 07...
  • Page 43 DOUT1, 18 - controlling DOUT2. Enabling electronic ID 0 – disabled; 1 - iButtonEn 0991 none 1 byte none enabled Enabling thermometer 0 – disabled; 1 - TsensEn 0990 none 1 byte none support enabled www.bitrek.com.ua sales@bitrek.com.ua +380 44 507 02 07...
  • Page 44 4 byte none received IDs of CAN-messages canID4 3329 none 4 byte none received IDs of CAN-messages canID5 3330 none 4 byte none received IDs of CAN-messages canID6 3331 none 4 byte none received www.bitrek.com.ua sales@bitrek.com.ua +380 44 507 02 07...
  • Page 45 Mask of bytes received c.u. 0 - 255 CAN_ DMASK_ID 0328 none 2 byte Mask of bytes received c.u. 0 - 255 CAN_ DMASK_ID 0329 none 2 byte Mask of bytes received c.u. 0 - 255 www.bitrek.com.ua sales@bitrek.com.ua +380 44 507 02 07...
  • Page 46 Mask of bytes received c.u. 0 - 255 CAN_ DMASK_ID 0333 none 2 byte Mask of bytes received c.u. 0 - 255 CAN_ DMASK_ID 0334 none 2 byte Mask of bytes received c.u. 0 - 255 www.bitrek.com.ua sales@bitrek.com.ua +380 44 507 02 07...

  • Page 47: Addendum 2. List Of I/O Components

    0475 0480… Profile 1 byte Profile number none 0485 0510… Movement 1 byte Movement status none 0515 0300… AIN1 2 byte Analog input 1 0305 0310… AIN2 2 byte Analog input 2 0315 www.bitrek.com.ua sales@bitrek.com.ua +380 44 507 02 07...
  • Page 48 0580… fuelLevel1 2 byte meter (network address c.u. 0585 Polling filtered fuel 0590… fuelLevel2 2 byte meter (network address c.u. 0595 Polling filtered fuel 0850… fuelLevel5 2 byte meter (network address c.u. 0855 www.bitrek.com.ua sales@bitrek.com.ua +380 44 507 02 07...
  • Page 49 (network °C 0615 address 2) Fuel temperature per 0520… fuelTemp5 1 byte fuel meter (network °C 0525 address 5) Fuel temperature per 0530… fuelTemp6 1 byte fuel meter (network °C 0535 address 6) www.bitrek.com.ua sales@bitrek.com.ua +380 44 507 02 07...
  • Page 50 8 byte none 0405 electronic key 0680… Transmission of OperCode 4 byte none 0685 carrier's code 0750… Transmission of device 0 - not active; 1 - modemStat 1 byte none 0755 modem status active; www.bitrek.com.ua sales@bitrek.com.ua +380 44 507 02 07...
  • Page 51 1 - home network; 2 - not registered, but 0760… GSM network GSM_Stat 1 byte none searching for 0765 registration status carriers; 3 - registration disabled; 4 - status unknown; 5 - roaming; www.bitrek.com.ua sales@bitrek.com.ua +380 44 507 02 07...
  • Page 52 5 sec) Instantaneous pulse 0320… fast_dlLow1 4 byte counter (minimum c.u. 0325 measurement is 1mS) Pulse counter saving pulseCount 3810… the values to non- 4 byte c.u. _dlLow3 3815 volatile memory. (dlLow3) www.bitrek.com.ua sales@bitrek.com.ua +380 44 507 02 07...
  • Page 53 0 - 255 0735 angle Actual value of Z- 0740… axesZ 1 byte direction elevation degrees 0 - 255 0745 angle 0800… Horizontal accuracy HDOP 2 byte c.u. 0 - 9999 0805 determination www.bitrek.com.ua sales@bitrek.com.ua +380 44 507 02 07...
  • Page 54 3680… Activation of I/O setIO_CAN7 8 byte c.u. 3685 component CAN7 3690… Activation of I/O setIO_CAN8 8 byte c.u. 3695 component CAN8 3700… Activation of I/O setIO_CAN9 8 byte c.u. 3705 component CAN9 www.bitrek.com.ua sales@bitrek.com.ua +380 44 507 02 07...
  • Page 55 Changed the firmware update port number 09.10.2018 Ver.2018.10.1 Added new I/O element IDconf 0907 The description of the section describing the 09.09.2019 Ver.2019.09.1 principle of working with the list of prohibited operators has been expanded. www.bitrek.com.ua sales@bitrek.com.ua +380 44 507 02 07...
