5. Remove power from the controller.
6. Hold down the LED POWER button.
7. Apply power to the controller.
8. Continue holding the LED POWER button until the STAT LED turns on.
9. Release the LED POWER button.
Note: If the LED POWER button is released before the STAT LED turns on, the SCADAPack
controller will start in RUN mode.
13.1.3

Cold Boot Mode

COLD BOOT mode is used after installing new controller firmware. When a SCADAPack 350
controller starts in COLD BOOT mode:
•
The default serial and Ethernet communication parameters are used (see section 10- Serial
Communication and 11-Ethernet Communication for a description of the default parameters).
•
The TelePACE Ladder Logic or ISaGRAF and C Tools programs are erased.
•
The C program is erased.
•
The registers in the I/O database or I/O Connection are initialized to their default values.
•
The Register Assignment is erased.
•
The controller is unlocked.
COLD BOOT mode is selected by performing a COLD BOOT using the following procedure:
1. Remove power from the SCADAPack controller.
2. Hold down the LED POWER button.
3. Apply power to the SCADAPack controller.
4. Continue holding the LED POWER button for 25 seconds until the STAT LED begins to flash
on and off continuously.
5. Release the LED POWER button.
Note: If the LED POWER button is released before the STAT LED begins to flash, the
SCADAPack controller will start in SERVICE mode.
13.1.4

Factory Boot Mode

FACTORY BOOT mode is used to reformat the Flash File system and initialize the SCADAPack
350 controller to factory default settings. When the controller starts in FACTORY BOOT mode:
•
The default serial and Ethernet communication parameters are used (see section 10- Serial
Communication and 11-Ethernet Communication for a description of the default parameters).
•
The TelePACE Ladder Logic or ISaGRAF and C Tools programs are erased.
•
The C program is erased.
•
The registers in the I/O database or I/O Connection are initialized to their default values.
•
The Register Assignment is erased.
•
The controller is unlocked.
•
Flash File system is reformatted.
