13.1.8

Power Consumption

The power consumption of the SCADAPack 350 should be less than the values in the table
below:
Power
Mode
Normal
Normal
Normal
Normal
Reduced
Reduced
Reduced
Reduced
Sleep
13.2

LED Indicators

There are 25 LEDs on SCADAPack 350. All LEDs can be disabled to conserve power. The table
below describes the LEDs.
LED Function
Power On when operating and the LEDs are enabled.
Mode
Off when the LEDs are disabled.
Off when powered off or in Sleep Mode.
RUN On when the ladder logic program is executing.
STAT Blinking when an error exists.
FORCE On when I/O points are forced.
LINK On when the LAN port has established a link
ACT. On to signal activity on the LAN port
RX On when receiving data on the corresponding serial port.
TX On when transmitting data on the corresponding serial port.
CTS On when the CTS input is asserted COM2.
DCD On when the DCD input is asserted COM2.
Digital I/O On when the corresponding I/O point is on. LEDs are dim in Sleep
Mode when the corresponding I/O point is on.
Counter 0 On when the counter input is present and low.
Counters When the input is configured to use an external amplifier, the LED
1,2 is on when the counter input is present and low.
When the input is configured to use the internal amplifier, the LED
is on when input pulses are present.
13.3

LED Power Control

The SCADAPack 350 controller board can disable the LEDs on the controller board and the 5000
Series I/O modules to conserve power. This is particularly useful in solar powered or unattended
installations.
SCADAPack 350 Hardware Manual
February 14, 2007
LAN USB
Status Status
Enabled Enabled
Enabled Disabled
Disabled Enabled
Disabled Disabled
Enabled Enabled
Enabled Disabled
Disabled Enabled
Disabled Disabled
Any Any
Power Consumption
(mW)
1750
1500
1000
750
1500
1250
750
500
15
