Pin
Function
8
RTS (Output)
SCADAPack 350 Hardware Manual
February 14, 2007
Description
When the attached device does provide this signal, it must
set CTS to MARK to allow the controller to transmit data.
This pin is a MARK if full-duplex operation is selected for the
port.
This pin is set to a MARK just before and during
transmission of data if half-duplex operation is selected.
This pin is set to a SPACE when no data is being
transmitted.
The LED is ON for a MARK level.
31
