- Page 1 SCADAPack Micro 16 Quick Start Guide CONTROL MICROSYSTEMS SCADA products... for the distance 48 Steacie Drive Telephone: 613-591-1943 Kanata, Ontario Facsimile: 613-591-1022 K2K 2A9 Technical Support: 888-226-6876 Canada 888-2CONTROL...
- Page 2 Printed in Canada. Trademarks TeleSAFE, TelePACE, SmartWIRE, SCADAPack, TeleSAFE Micro16 and TeleBUS are registered trademarks of Control Microsystems Inc. All other product names are copyright and registered trademarks or trade names of their respective owners. Material used in the User and Reference manual section titled SCADAServer OLE Automation Reference is distributed under license from the OPC Foundation.
-
Page 3: Table Of Contents
9. Program Ladder Logic................9 3.10 10. Configure Monitor List ................9 3.11 11. Write Ladder Logic to the Controller ............9 3.12 12. Monitor On Line Mode ................9 TROUBLESHOOTING ................. 11 SCADAPack Micro 16 Quick Start Guide October 19, 2007... -
Page 4: Overview
A strong background in both programmable logic controllers (PLC) and personal computers (PC) using Windows is highly recommended. If any problems arise during the setup, it may be necessary to then consult the appropriate manual or call the Control Microsystems Technical Support Department for assistance. -
Page 5: Important Safety Information
EXPLOSION HAZARD – WHEN IN HAZARDOUS LOCATIONS, TURN OFF POWER BEFORE REPLACING OR WIRING MODULES. WARNING ! EXPLOSION HAZARD - DO NOT DISCONNECT EQUIPMENT UNLESS POWER HAS BEEN SWITCHED OFF OR THE AREA IS KNOWN TO BE NONHAZARDOUS. SCADAPack Micro 16 Quick Start Guide October 19, 2007... -
Page 6: Quick-Start Procedure
Release the LED POWER button. LED Power Button Connect Computer to TeleSAFE Micro 16 Connect a null modem cable from the computer serial port to com2 on the TeleSAFE Micro 16 controller board. SCADAPack Micro 16 Quick Start Guide October 19, 2007... -
Page 7: Install Telepace Software
Select the Default button (lower right side of dialog box) and then change the Port (upper right side of dialog box) to reflect the computer serial port assignment. Select OK to close the dialog box. SCADAPack Micro 16 Quick Start Guide October 19, 2007... -
Page 8: Select Controller Type
If on-board modules are to be used, select ADD and enter the module which corresponds to the particular on-board module. Enter an appropriate Modbus register address in the Start box. Repeat this step for each on-board module. SCADAPack Micro 16 Quick Start Guide October 19, 2007... -
Page 9: Configure Controller Serial Ports
Configure Controller Serial Ports Select Controller – Serial Ports and modify the settings for com1, if applicable. The following example shows how com1 would be programmed to communicate via an external dial-up modem. SCADAPack Micro 16 Quick Start Guide October 19, 2007... -
Page 10: Program Ladder Logic
Select Communications – Write to Controller and write the ladder logic to the controller by selecting Start from the dialog. 3.12 Monitor On Line Mode Select Activity – Monitor Online and follow the screen prompts: To Log On to the Controller, select Start. SCADAPack Micro 16 Quick Start Guide October 19, 2007... - Page 11 To Switch to Debug to monitor the program execution, select Yes. The following Monitor List will appear and display the registers that were added to the Monitor List in step 11. The Quick-Start procedure is complete! SCADAPack Micro 16 Quick Start Guide October 19, 2007...
-
Page 12: Troubleshooting
If any problems occur at any step in the procedure, review the pertinent steps to ensure that they have been followed correctly. If you are unable to resolve the problem, please contact the technical support department at Control Microsystems for further assistance. Toll Free Technical Support Users in Canada and the United States may call our technical support department free of charge.
