Specifications

Disclaimer: Control Microsystems reserves the right to change product specifications without
notice. For more information visit
16.1

General

I/O Terminations
Dimensions
Packaging
Environment
16.2

Controller

Processors
Memory
Non-volatile
RAM
Clock calendar
Internal
temperature
Lithium battery
Monitor
Power Input
Voltage Monitor
16.3

Communications

Communication
Port COM1
Communication
Port COM2
SCADAPack 350 Hardware Manual
February 14, 2007
www.controlmicrosystems.com
6 and 12 pole, removable terminal blocks.
12 to 22 AWG
15A contacts
8.40 inch (213mm) wide
5.00 inch (127 mm) high
1.80 inch (45mm) deep
Corrosion resistant zinc plated steel with black enamel paint
5% RH to 95% RH, non-condensing
o o
–40 C to 70 C
o o
–40 F to 158 F
32-bit ARM7-TDMI microcontroller, 32 MHz clock
integrated watchdog timer
Two Microcontroller co-processors, 20 MHz clock
16MBytes FLASH ROM
4MBytes CMOS RAM
4kBytes EEPROM
CMOS RAM with lithium battery retains contents for 2 years
with no power
±1 minute/month at 25°C
+1/–3 minutes/month 0 to 50°C
Measurement range -40°C to 75°C. Accuracy ±5°C.
Measurement range -40°F to 167°F. Accuracy ±9°F.
Accuracy ±0.2V.
Accuracy ±0.4V.
RS-485 serial port
removable terminal block
Two-wire half duplex
Bias resistors installed.
Jumper configurable RS-232 or RS-485
RS-232 compatible serial port (±5V)
Data Terminal Equipment (DTE)
8 pin modular jack
.
