Cold Boot Mode

COLD BOOT mode is used after installing new controller firmware. When the SCADAPack 32P
controller starts in COLD BOOT mode:
The default serial communication parameters are used. See section 4.1-RS-232 Serial
Communications Ports of this manual for a description of the default parameters.
The default TCP/IP parameters are used for the Ethernet port. See section 5.1.1-TCP/IP Settings of
this manual for the default parameters.
•
The default Modbus/TCP parameters are used for the Ethernet port. See section 5.1.2-
Modbus/TCP Settings of this manual for the default parameters.
•
The TelePACE or ISaGRAF application program is erased.
•
The ISaGRAF C++ application program is erased.
•
The controller is unlocked.
COLD BOOT mode is selected by performing a COLD BOOT using the following procedure:
•
Remove power from the controller.
•
Hold down the LED POWER button.
•
Apply power to the controller.
•
Continue holding the LED POWER button for 25 seconds until the STAT LED begins to flash
on and off continuously.
•
Release the LED POWER button.
Note: If the LED POWER button is released before the STAT LED begins to flash, the
SCADAPack 32P controller will start in SERVICE mode.
6.4

SCADAPack 32P LED Indicators

There are twenty-three LEDs on the SCADAPack 32P SCADAPack 32P. These LEDs are used to
indicate the operational status of the controller. All LEDs except the 5V LED can be disabled to
conserve power. Refer to section 6.5-LED Power Control for details on LED power control.
The following table describes the SCADAPack 32P SCADAPack 32P LEDs.
LED
5V
RUN
LEDS
STAT
FORCE
SCADAPack 32P Controller Hardware Manual
May 26, 2006
Function
On when 5V power is present in the SCADAPack 32P
controller. The controller must have 5V power to operate. 5V
power is supplied by the SCADAPack 32P internal power
supply or from an external model 5103 power supply.
On when an ISaGRAF application program is running in the
SCADAPack 32P controller. This LED may be controlled by
a C++ Tools application, in which case the application will
control the LED status.
On when LED power is enabled.
This LED is normally off. The LED will blink when an error
exists. Refer to section for more information on this LED
and the STATUS output.
On when and SCADAPack 32P I/O points are forced, or
locked, in an ISaGRAF application.
