Norac UC4 Plus Installation Manual

Spray height controller fast 120' passive roll
Hide thumbs Also See for UC4 Plus:
Table of Contents

Advertisement

Quick Links

Download this manual
Spray Height Controller
Fast 120' Passive Roll
Installation Manual
Improving the competitiveness of Industry and
Agriculture through Precision Measurement

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UC4 Plus and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Norac UC4 Plus

Summary of Contents for Norac UC4 Plus

  • Page 1 Spray Height Controller Fast 120’ Passive Roll Installation Manual Improving the competitiveness of Industry and Agriculture through Precision Measurement...
  • Page 2 Reorder P/N: UC4+BC+FT2-INSTh (Fast 120’ Passive Roll) NORAC Systems International Inc. reserves the right to improve products and their specifications without notice and without the requirement to update products sold previously. Every effort has been made to ensure the accuracy of the information contained...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION ..........................1 GENERAL SYSTEM DESCRIPTION ....................2 PARTS LISTS ............................3 INSTALLATION PROCEDURE ......................8 ........................8 ENSOR NSTALLATION ....................... 10 ENSOR NSTALLATION 4.2.1 Boom Roll Sensor Mounting....................12 4.2.2 Chassis Roll Sensor Mounting ....................12 4.2.3 Inverted Roll Sensor Mounting ....................

  • Page 4: Introduction

    INTRODUCTION Congratulations on your purchase of the NORAC UC4+ Spray Height Controller. This system is manufactured with top quality components and is engineered using the latest technology to provide operating features and reliability unmatched for years to come. When properly used the system can provide protection from sprayer boom damage, improve sprayer efficiency, and ensure chemicals are applied correctly.

  • Page 5: General System Description

    Any installation specially to fit the sprayer to facilitate a procedure requiring boom movement will complete installation. However, NORAC need to be done first. Once the hydraulics cannot guarantee all parts fit as intended due have been disconnected you must complete...

  • Page 6: Parts Lists

    CABLE EXTENSION VALVE GENERIC 4461BC+ UC4 PLUS BOOM CONTROL PANEL 44631 UC4 ULTRASOUND SENSOR 44641 UC4 PLUS ROLL SENSOR W TEMPERATURE PROBE 44642 UC4 PLUS ROLL SENSOR 44865-09 HYDRAULICS FITTING KIT - FT1 446BC+MAN7 OPERATOR MANUAL UC4+ SPRAY HEIGHT CONTROL...
  • Page 7 Substitution parts will in no way affect the operation of the system provided that they are installed as directed. Item V01 – 2 Station Valve Block (44963D) may be substituted with: Item Part Number Name Quantity 44933D VALVE BLOCK ASSEM UC4-BC 2-STATION CC/LS VARIABLE RATE The 44933D is a direct replacement for the 44963D.
  • Page 8 FACE P - PIPE The use of dielectric grease is not recommended on any NORAC electrical connections. To ensure all stainless steel hardware does not gall or seize apply a light coating of the supplied Permatex Anti-seize grease to all threaded parts upon installation. Permatex Anti-seize lubricant is...
  • Page 9 The parts that come with your UC4+ System are shown below in their general installation configuration. Figure 2 – UC4+ Spray Height Controller Components...
  • Page 10 Figure 3 – Hydraulic Plumbing Schematic...

  • Page 11: Installation Procedure

    INSTALLATION PROCEDURE 4.1 S ENSOR NSTALLATION General mounting rules for UC4+ Mounting the sensor bracket to ultrasonic sensors: the break-away section of the boom may cause the boom to drop a) In its lowest position, the sensor mouth suddenly as a break-away occurs. must be 9 inches or more from the This will occur on break-away ground.
  • Page 12 3 SENSOR SYSTEM 5 SENSOR SYSTEM Figure 6 – Sensor Serial Number Installation Location...

  • Page 13: Roll Sensor Installation

    4.2 R a) The smaller the distance between A and ENSOR NSTALLATION better Figure Mount the roll sensors to the included roll performance will be. sensor brackets using the machine screws and nylon lock nuts. (Figure 7) Distance A can not be more than 12”. b) The roll sensors must not be mounted The roll sensors must be mounted below the pivot point.
  • Page 14 * The boom frame roll sensor does not have a temperature probe Figure 9 – Roll Sensor Mounting with Respect to Sprayer Orientation Chassis Roll Boom Frame Roll Sensor Sensor Figure 10 - Roll Sensors Mounted on a Fast...

  • Page 15: Boom Roll Sensor Mounting

    4.2.2 Chassis Roll Sensor Mounting 4.2.1 Boom Roll Sensor Mounting The boom roll sensor (E02) must be The chassis roll sensor must be mounted mounted to the rotating part of the boom. to a non-rotating part of the boom. To Follow these guidelines and refer to mount the chassis roll sensor, follow the Figure 11 to mount the sensor.

  • Page 16: Inverted Roll Sensor Mounting

    4.2.3 Inverted Roll Sensor Mounting connector exits towards the right-hand boom. Inverted mounting may be used If desired, the Roll sensor may be optimize mounting criteria mounted inverted, so long as the explained in Section 4.2. Figure 12 – Inverted Roll Sensor Mounting may be Applicable for Optimal Performance 4.2.4 Temperature probe Fasten the temperature probe (E03) to the UC4 valve block using the included...

  • Page 17: Hydraulic Installation

    “B” ports and tighten to 18 ft-lbs. 4. Install the 6MB-plugs (F05) into the “A” ports and tighten to 18 ft-lbs. 5. Mount the NORAC valve (V01) to the sprayer in a suitable location. 44933D Figure 14 – NORAC Valve Block 2.

  • Page 18: Hydraulic Plumbing

    4.3.2 Hydraulic Plumbing 3. Tee in the pressure (“P”) and tank (“T”) lines for the NORAC block in to the existing lines from the valve block, 1. After the NORAC valves are mounted, using the “T” fitting (F03). the hydraulic hoses and fittings can be plumbed.

  • Page 19: Electrical Installation

    5. Connect the Deutsch connectors on C05 on the 44963D block. to the Fast valve block, by using the connector labels on the cable. 6. Install the 2-pin connectors from C03 onto each NORAC valve as shown in Figure 17.
  • Page 20 44933D Figure 18 – Cable Configurations: C02, C02B and C11 IMPORTANT: Provide enough slack in all cables to account for the movement of the main section, parallel lift, and FOLDING boom movement. 44963D Figure 17 – Valve Cable Connections 8. Connect the sensor branch cable (C02) to the 4-pin AMP plug (P4) on C11 (Figure 18).

  • Page 21: Completing The Factory Install

    1. Test the functionality of the original manufacturer’s boom controls. 4. For the FT2 system it is recommended NORAC Control Panel (Item E01) does that a full software install be done prior not need to be powered up for the to delivery of the sprayer.

  • Page 22: End User Installation

    END USER INSTALLATION 1. Install the UC4+ Control Panel (E01) in the cab of the sprayer. Mount the panel where it will be clearly visible and within easy reach of the operator. A good spot to mount the UC4+ control panel is on the right hand side of the cab to the Roll Over Protection Bar.
  • Page 23 Figure 20 – Cable Configurations: C10 and C11 2. Connect the power cable (C10) to 5. For optimal performance of the UC4 the UC4+ Control Panel in the system, there should be very little sprayer cab. Ensure that both plugs play at the hitch clevis.

  • Page 24: Electrical Reference - Cable Drawings

    ELECTRICAL REFERENCE – CABLE DRAWINGS 6.1 I C02: 44668 – S ENSOR RANCH ABLE...

  • Page 25: Item C03: 44656D - Cable Valve Variable Rate Dt

    6.2 I C03: 44656D – C ABLE ALVE ARIABLE...

  • Page 26: Item C10: 44650-35 - Power Cable Generic Pull -Type

    6.3 I C10: 44650-35 – P OWER ABLE ENERIC...

  • Page 27: Item C11: 44651-03 - Extension Cable Valve Generic

    6.4 I C11: 44651-03 – E XTENSION ABLE ALVE ENERIC...

  • Page 28: Item C05: 44658-73 - Cable Fasta & L Block Interface Dt

    6.5 I C05: 44658-73 – C A & L B ABLE LOCK NTERFACE...
  • Page 29 Canada NORAC Systems International Inc. CALL TOLL FREE: 1-800-667-3921 (306)664-6711 SHIPPING ADDRESS: 3702 Kinnear Place Saskatoon, SK S7P 0A6 United States NORAC, Inc. CALL TOLL FREE: 1-866-306-6722 (763)786-3080 SHIPPING ADDRESS: 1290 Osborne Rd NE, Suite F Fridley, MN 55432-2892...
