20" E
SKU #
MODEL #
21200
MS20-5B/230/1
21500-230
MS20-5B/230/3
21500-460
MS20-5B/460/3
21300-230
MS20-7.5B/230/3
21300-460
MS20-7.5B/460/3
READ AND UNDERSTAND THE OPERATOR'S SAFETY MANUAL THOROUGHLY
BEFORE ATTEMPTING TO OPERATE THIS EQUIPMENT.
Death or serious injury could occur if this machine is used improperly.
Machine speci ic Operator's Instruction Manuals are offered at www.discount-equipment.com
THE ENGINE MANUFACTURERS INSTRUCTIONS AND OPERATORS MANUAL BEFORE OPERATION.
PARTS LIST MANUAL
MODEL MS20
P
LECTRIC
OWERED
POWER OPTION
BALDOR ELECTRIC MOTOR 5HP 230V 1-PHASE 60HZ
BALDOR ELECTRIC MOTOR 5HP 230V 3-PHASE 60HZ
BALDOR ELECTRIC MOTOR 5HP 460V 3-PHASE 60HZ
BALDOR ELECTRIC MOTOR 7.5HP 230V 3-PHASE 60HZ
BALDOR ELECTRIC MOTOR 7.5HP 460V 3-PHASE 60HZ
M
S
ASONRY
AWS
READ AND UNDERSTAND
E-MS20-PL-1018
REVISED STARTING
SERIAL # 181010494
Printed in USA
©2018
JWA
Page 1
