- Page 1 INSTRUCTION MANUAL PERISTALTIC PUMPS MULTIHEADS Model D-25VXi and D-25VTXi June 2019 Marked c/ Encarnació, 123 -125. Phone +34 93 284 69 62. Fax +34 93 210 43 E-mail: dinter@dinko.es www.dinko.es 08024 – BARCELONA...
-
Page 2: General Introduction
Unitized instruments contains a peristaltic pump, speed control and on-of switch for each head pump in a single case. The peristaltic pumps D-25VXi has heads that facilitates the extraction of the tube when it should substitute or for sterilisation. In the pumps with 50-2r head type retires the cover extracting the three screws. The head pump CF-3r and CF- 4r is for easy change tube Each pump admits four or six tube sizes giving the interval flows ranges in the table. - Page 3 Tube loading, CF pump head X- Not well installed tube V- Well installed tube Pump head 1500 Cover fixing screws Pump head 5000 -Description and adjustment. Lock Flexible rotor lid Roller Protection lid Hose guide roller Tube clamp Track Rotor Tube clamp Clutch button lid Support roller...
- Page 4 ◊ Reassemble the split collet on the shaft, rotating it until it is fully inserted. Fit the body of the rotor drive shaft as a unit. ◊ Open the flexible black cover of the center rotor. With a Phillips screwdriver to tighten the screw positioning a pair of 3 Nm to prevent the collet slipping during work.
- Page 5 Starting from the tube of 4,8 mm the necessary minimum speed is the following one: Tube 4,8 mm / 5%. Tube 6,4 mm/10%. tube 8 mm/15%. It is convenient to lubricate the tubes lightly with silicone grease to use smaller speed and increase the life tube.
-
Page 6: Mode Of Operation
GENERAL TECHNICAL CHARACTERISTICS PHYSICAL CHARACTERISTICS Ranges: 8 selected by screen. Display: L.C.D backlight of 8 digits. Output: contact relay commuted. Box: grey colour manufactured in UL 94 - V-0 Polycarbonate ENVIRONMENTAL CONDITIONS Fixation in panel: With support by pressure. Format: 48mm x 48 mm. Temperature of work:-10 ºC +55 º... - Page 7 Place again the cover. Pump head CF, see “Description section”. Pump head 5000, see “Description section”. The supply and discharge tubes can have any thickness wall, but the tube that settles in the pump head should have a calibrated thickness wall of 1,6 mm. and 2,4 mm for the pump head 1500. All the pumps are supplied with medical /alimentary degree silicone tube according to FDA norms and USP.
-
Page 8: Maintenance / Spares
All initiative should be made by qualified personnel to avoid bigger wrongs. Trust their apparatus to a technical service authorized by DINKO Instruments. The motor and block of the dispenser pump don't require lubrication for what they don't have maintenance. It is convenient to lubricate the rollers lightly with silicone grease. -
Page 9: What Is Not Covered
Dinko be liable for any collateral or consequential damagages or loss “CE” DECLARATION OF CONFORMITY DINTER S. A. DINKO Instruments, c/ Encarnació, 123-125 / 08024-Barcelona Declare that the products mentioned in attached list, to which this declaration relates, comply with the essential safety requirements of the relevant European Directive. - Page 10 OTHER DINKO APPARATUS - Colorimeters - Extractor for mince analysis - Heater Metallic Blocks - Heater Plates - Infrared Ovens - Kits for Water Analysis - Magnetic Stirrers. - Muffle Furnaces to 1200ºC - Nephelometers - Orbital Shakers - Peristaltic Pumps - Photometers -Respirometers - Rod Stirrers...
