Avoid using the device when there is the possibility of generating explosive and flammable gas mixtures. 2- PACKING LIST Description Code Quantity Peristaltic Pump D-25V plus 1. 9731.15 / 1.9731.30 / 1.9731.80 /1.9731.24 0-10V connector Footswitch connector Set of tubes and seals...
3- RECEPTION To ensure correct reception, use of the device, and user safety, we recommend reading this manual in detail before proceeding to unpack the device and subsequent use, and especially the following points: 3.1-THE MANUAL This manual must be permanently kept within the equipment user's reach. 3.2-UNPACKING Unpack the appliance, checking that the contents match the packing list.
4- DESCRIPTION The D-25V plus peristaltic pumps are provided with a head that allows access to the tube for its extraction when it must be replaced due to wear or for sterilization. On CFV-4r head pumps, the head is opened by pulling the top upwards, allowing access for tube replacement.
Page 6
TUBE INSTALLATION The tube retainers for the CFV-4r head are different depending on the size of the tube being installed. To insert the tube retainers: 1-Lift the head cover by pulling it up. 2-Place the retainer of the horizontal tube to the body of the head. 3-4.
Page 7
4.2- DESCRIPTION OF THE FRONT PANEL A-Digital Reader 1-key direction of rotation 2-key direction of rotation 3-Key Full 4-Start / Stop key-Memo start 5 and 6- Decrease and increase keys. 7- Switch for programming 4.3- DESCRIPTION OF THE REAR PANEL 7 - Main ON/OFF switch 8 - Fuse box 9 - Power socket...
5- START UP Make sure that the mains voltage is between 110 and 230 V. Connect the power cable to the rear plug and to the network. Consult the indicative flow table and install the appropriate tube. See tips in the Tube Change and Head Description section. Select the desired function.
Page 9
· Cycle Programming Function 1- Connect to the network. 2- Keep keys nº1 and nº3 pressed while operating the rear ON/OFF general switch nº7 and then the front switch nº13. The green light will light up and the yellow light of the nº1 key will light intermittently.
6- CHANGE OF TUBES Press the OFF switch. Extract the tube according to the indications described in the “Description” and “Heads” section. When the new tube is installed, it should be centered over the rollers to prevent the rotor from pinching it. Install the tube retainers on each side of the tube, at the outlet and inlet, corresponding to the size of the tube chosen.
AVAILABLE MATERIALS The most mechanically resistant tubes are PHARMA, TYGON A-60-C ®, TYGON A-60-G ® and SILICONE with medium duration, but durability also depends to a large extent on the chemical nature of the pumped liquid, the pressure, existing temperature and naturally the engine revolutions. Proper choice of tubing ID prevents higher RPM demand from the peristaltic pump motor with small diameter tubing and decreased tubing life.
Before any examination or repair of the appliance, it is necessary to disconnect the mains plug. Any initiative must be carried out by qualified personnel to avoid greater evils. Entrust your device to a technical service authorized by DINKO Instruments. The engine and its block do not require greasing, so they do not have maintenance.
9- ACCESSORIES CONNECTORS FOR PERISTALTIC TUBES 9.1: Reducing Connectors - Splice / Same Ends, Polypropylene For 1.6/3.2 mm internal Ø tubes. Code1.0080.15 For 3.2/4.8 mm internal Ø tubes. Code 1.0080.18 For 4.8/6.4 mm internal Ø tubes. Code 1.0080.05 For 6.4/8 mm internal Ø tubes. Code 1.0080.14 For 8/12.7mm internal Ø...
Page 14
9.7: Polypropylene stopcock Wrench for internal Ø tubes 4.8-8.00mm. Code 1.0120.39 9. 8: Foot support with clamp. Code 1.8003.08 Useful as a support for the tube/dispensing tip. Foot: 30 x 15cm. Bar, height 70cm. sliding clamp 9.9: Silicone Grease, 50g for lubricating peristaltic tubes. Code 8.0030.03 9.10 Balance for flow and dosage calibration.
10- CHANGE OF FUSES The fuse box is part of the power base located at the rear of the pump. See Figure. main switch Fuse box power base Pry with a screwdriver between the central part of the fuse holder box and the upper part of the power supply base to remove the fuse holder box.
12- WARRANTY 12.1 DURATION: The guarantee is established for a period of 1 year from the date of commissioning of the device, provided that the guaranteed card is returned to us within 8 days of said commissioning. Without this condition the guarantee will not be valid. 12.2 SCOPE OF WARRANTY: The guarantee is given against manufacturing and material defects for an average work week of 40 hours.
13- “CE” DECLARATION OF CONFORMITY DINTER SA DINKO Instruments c/ Encarnació, 123-125 / 08024- Barcelona Declares that the items mentioned in the attached list, to which this declaration refers, comply with the essential safety requirements of the applicable European Directive:...
