- Page 1 OPTIWAVE 7300 C OPTIWAVE 7300 C OPTIWAVE 7300 C Quick Start Quick Start Quick Start Quick Start Non-contact Radar (FMCW) Level Meter for distance, level and volume measurement of liquids © KROHNE 04/2009 - 4000050002 - QS OPTIWAVE 7300 R05 en...
-
Page 2: Table Of Contents
4.3.4 How to start the device ......................32 4.4 Remote communication with PACTware™ ..............32 4.5 Remote communication with the AMS™ Device Manager..........33 5 Technical data 5.1 Technical data......................... 34 www.krohne.com 04/2009 - 4000050002 - QS OPTIWAVE 7300 R05 en... - Page 3 CONTENTS OPTIWAVE 7300 C 6 Notes 04/2009 - 4000050002 - QS OPTIWAVE 7300 R05 en www.krohne.com...
-
Page 4: Safety Instructions
If you need to return the device to the manufacturer or supplier, please fill out the form • contained on the CD-ROM and send it with the device. Unfortunately, the manufacturer cannot repair or inspect the device without the completed form. www.krohne.com 04/2009 - 4000050002 - QS OPTIWAVE 7300 R05 en... -
Page 5: Installation
Figure 2-1: Scope of delivery - horn antenna 1 Signal converter and antenna in compact version 2 Antenna extensions (option) 3 Quick Start 4 CD-ROM (including Handbook, Quick Start, Technical Datasheet and related software) 04/2009 - 4000050002 - QS OPTIWAVE 7300 R05 en www.krohne.com... - Page 6 2 Antenna extensions (option) and o-ring for each antenna extension 3 Quick Start 4 CD-ROM (including Handbook, Quick Start, Technical Datasheet, and related software) INFORMATION! No special tools or training required! www.krohne.com 04/2009 - 4000050002 - QS OPTIWAVE 7300 R05 en...
-
Page 7: Visual Check
Look at the device nameplate to ensure that the device is delivered according to your order. Check for the correct supply voltage printed on the nameplate. INFORMATION! Compare the material reference on the side of the process connection with the order. 04/2009 - 4000050002 - QS OPTIWAVE 7300 R05 en www.krohne.com... -
Page 8: Storage
3 Storage temperature range: -40...+85°C / -40...+185°F • Store the device in a dry and dust-free location. • Keep the converter out of the sunlight. • Store the device in its original packing. www.krohne.com 04/2009 - 4000050002 - QS OPTIWAVE 7300 R05 en... -
Page 9: Transport
EN 50178 and IEC 60068-2-6. To make sure that you install the device quickly, easily and safely, prepare the installation as given in the instructions that follow. 04/2009 - 4000050002 - QS OPTIWAVE 7300 R05 en www.krohne.com... -
Page 10: How To Prepare The Tank Before You Install The Device
Maximum process connection temperature: Maximum process connection temperature: Maximum process connection temperature: PTFE Drop antenna option: +150 C / +300 ° ° PP Drop antenna option: +100 C / 210 ° ° www.krohne.com 04/2009 - 4000050002 - QS OPTIWAVE 7300 R05 en... -
Page 11: Theoretical Data For Nozzle Position
Do not put the device near to the product inlet. If the product that enters the tank touches the antenna, the device will measure incorrectly. If the product fills the tank directly below the antenna, the device will also measure incorrectly. 04/2009 - 4000050002 - QS OPTIWAVE 7300 R05 en www.krohne.com... - Page 12 2 The device is too near to the product inlet. Figure 2-9: More than 1 FMCW radar level meter can be operated in a tank More than 1 FMCW radar level meter can be operated in a tank. www.krohne.com 04/2009 - 4000050002 - QS OPTIWAVE 7300 R05 en...
-
Page 13: Installation Recommendations For Liquids
• There are too many obstacles near to the area where you want to install the device. • The device is used to measure a liquid (petro-chemicals) in a tank with a floating roof. 04/2009 - 4000050002 - QS OPTIWAVE 7300 R05 en www.krohne.com... - Page 14 • Drill a liquid circulation hole in the stilling well above the maximum level of the interface (if there is more than 1 liquid in the tank). These holes help the liquid to move freely between the stilling well and the tank. • Deburr the holes. www.krohne.com 04/2009 - 4000050002 - QS OPTIWAVE 7300 R05 en...
- Page 15 If the device must be installed on a tank with a floating roof, install it in a stilling well. Figure 2-12: Floating roofs 1 Sediment 2 Support fixtures 3 Stilling well 4 Floating roof 5 Product 6 Tank 04/2009 - 4000050002 - QS OPTIWAVE 7300 R05 en www.krohne.com...
- Page 16 > advanced setup > Installation setup to keep the effects of multiple reflections supervisor mode > advanced setup > Installation setup supervisor mode > advanced setup > Installation setup to a minimum. For more data, refer to "Function description" in the handbook. www.krohne.com 04/2009 - 4000050002 - QS OPTIWAVE 7300 R05 en...
-
Page 17: Bypass Chambers
The bypass chamber must have a surface roughness of 0.1 mm / 0.004 • ± ¨ There must be no sudden changes in internal diameter greater than 1 mm / 0.04 • ¨ 04/2009 - 4000050002 - QS OPTIWAVE 7300 R05 en www.krohne.com... - Page 18 • Additional process connections are necessary for the liquids to circulate freely along the length of the bypass chamber. Figure 2-15: Installation recommendations for bypass chambers that contain more than one liquid 1 Bypass chamber 2 Additional process connection www.krohne.com 04/2009 - 4000050002 - QS OPTIWAVE 7300 R05 en...
-
Page 19: How To Install The Device On The Tank
• Align the gasket correctly on the flange facing of the nozzle. • Lower the antenna carefully into the tank. • Tighten the flange bolts. Refer to local rules and regulations for the correct torque to apply to the bolts. 04/2009 - 4000050002 - QS OPTIWAVE 7300 R05 en www.krohne.com... - Page 20 • Lower the antenna carefully into the tank. Do not attach to the tank yet. • Attach the antenna and the antenna locking screw • Lower the antenna carefully into the tank. Tighten the flange bolts. • Attach the antenna from inside the tank. www.krohne.com 04/2009 - 4000050002 - QS OPTIWAVE 7300 R05 en...
-
Page 21: How To Install A Device With A Threaded Connection
• Turn the threaded connection on the housing to attach the device to the process connection. • Tighten the connection. Refer to local rules and regulations for the correct torque to apply to the connection. 04/2009 - 4000050002 - QS OPTIWAVE 7300 R05 en www.krohne.com... - Page 22 • Align the gasket correctly. • Lower the antenna carefully into the tank. • If necessary, turn the threaded connection on the housing to attach the device to the plate. • Tighten the connection. www.krohne.com 04/2009 - 4000050002 - QS OPTIWAVE 7300 R05 en...
-
Page 23: How To Attach Antenna Extensions
Drop antenna: Make sure that there are not more than 5 antenna extensions attached to a device Drop antenna: Drop antenna: with a Drop antenna. If there are more than 5 antenna extensions, the device will not measure correctly. 04/2009 - 4000050002 - QS OPTIWAVE 7300 R05 en www.krohne.com... -
Page 24: How To Turn Or Remove The Signal Converter
• Turn the housing to the correct position. • Tighten the housing locking screw. CAUTION! If you remove the housing, put a cover on the wave guide hole in the flange assembly 2. www.krohne.com 04/2009 - 4000050002 - QS OPTIWAVE 7300 R05 en... -
Page 25: How To Attach The Weather Protection To The Device
• Attach the bracket. • Lift the weather protection to the top of the housing support pillar. • Hold the weather protection in the correct position and tighten the bracket nuts. 04/2009 - 4000050002 - QS OPTIWAVE 7300 R05 en www.krohne.com... -
Page 26: How To Open The Weather Protection
• Put a large slotted tip screwdriver into the keyhole at the front of the weather protection. • Turn the screwdriver counterclockwise. • Pull the top of weather protection up and forward. This will open the weather protection. www.krohne.com 04/2009 - 4000050002 - QS OPTIWAVE 7300 R05 en... -
Page 27: Electrical Connections
® Output 1 energizes the device and is used for HART communication. If the device has the second current output option, use a separate power supply to energize output 2. 04/2009 - 4000050002 - QS OPTIWAVE 7300 R05 en www.krohne.com... -
Page 28: Non-Ex
For electrical data for Ex d applications, refer to the Ex supplements. You can find this documentation on the CD-ROM delivered with the device or it can be downloaded free of charge from the website (Downloadcenter). www.krohne.com 04/2009 - 4000050002 - QS OPTIWAVE 7300 R05 en... -
Page 29: Protection Category
• The cables are in a loop in front of the device 1 so water does not go into the housing. • Tighten the cable feedthroughs 2. • Close unused cable feedthroughs with dummy plugs 3. 04/2009 - 4000050002 - QS OPTIWAVE 7300 R05 en www.krohne.com... -
Page 30: Start-Up
• A connection to a system or PC with AMS™. You can download the Device Description (DD) file from the internet site. ® • A connection to a HART Handheld Communicator. www.krohne.com 04/2009 - 4000050002 - QS OPTIWAVE 7300 R05 en... -
Page 31: Digital Display Screen
Press > and (Esc) at the same time to go back to the menu. If you do not touch the display for another 30 seconds, the message is shown again. 04/2009 - 4000050002 - QS OPTIWAVE 7300 R05 en www.krohne.com... -
Page 32: How To Start The Device
The software and installation instructions are given on the CD-ROM supplied with the device. You can also download the latest version of PACTware™ and the DTM from our internet site. Refer also to the PACTware™ consortium site at http://www.pactware.de. www.krohne.com 04/2009 - 4000050002 - QS OPTIWAVE 7300 R05 en... -
Page 33: Remote Communication With The Ams™ Device Manager
• Help plan preventive maintenance to reduce a plant's downtime to a minimum. The DD file is given on the CD-ROM supplied with the device. You can also download it from our internet site. 04/2009 - 4000050002 - QS OPTIWAVE 7300 R05 en www.krohne.com... -
Page 34: Technical Data
Display and user interface Display LCD display 9 lines, 160 x 160 pixels in 8-step greyscale with 4-button keypad Interface languages English, German, French, Italian, Spanish, Portuguese, Japanese, Chinese (Mandarin) and Russian www.krohne.com 04/2009 - 4000050002 - QS OPTIWAVE 7300 R05 en... - Page 35 Other conditions Other conditions ≥1.5 Dielectric constant (ε Vibration resistance IEC 60068-2-6 and EN 50178 (10...57 Hz: 0.075 mm / 57...150 Hz:1g) Protection category IP 66/67 equivalent to NEMA 6-6X 04/2009 - 4000050002 - QS OPTIWAVE 7300 R05 en www.krohne.com...
- Page 36 M25x1.5 (for stainless steel housings only) Cable gland Standard: none Options: M20x1.5 (for non-Ex and Ex -approved devices with M20x1.5 and M25x1.5 cable entries); others are available on request Cable entry capacity (terminal) 0.5…1.5 mm² www.krohne.com 04/2009 - 4000050002 - QS OPTIWAVE 7300 R05 en...
- Page 37 2 Kalrez® is a registered trademark of DuPont Performance Elastomers L.L.C. 3 Metaglas® is a registered trademark of Herberts Industrieglas, GMBH & Co., KG 4 HART® is a registered trademark of the HART Communication Foundation 04/2009 - 4000050002 - QS OPTIWAVE 7300 R05 en www.krohne.com...
- Page 38 NOTES OPTIWAVE 7300 C www.krohne.com 04/2009 - 4000050002 - QS OPTIWAVE 7300 R05 en...
- Page 39 NOTES OPTIWAVE 7300 C 04/2009 - 4000050002 - QS OPTIWAVE 7300 R05 en www.krohne.com...
- Page 40 Measuring systems for sea-going tankers Head Office KROHNE Messtechnik GmbH & Co. KG Ludwig-Krohne-Str. 5 D-47058 Duisburg (Germany) Tel.:+49 (0)203 301 0 Fax:+49 (0)203 301 10389 info@krohne.de The current list of all KROHNE contacts and addresses can be found at: www.krohne.com...
