EMP-Centauri MS5/5+12ECP5dB-4 Instruction Manual page 2

Specifications
Isolation of inputs
Max. input signal level TERR 110 dBμV, SAT 90 dBuV
Max. output signal
level (user outputs)
Current consumption
Dimensions
Temperature Range
*TERR: EN 50083-3/60dB IMA3 [dBuV]; SAT: EN 50083-3/35dB IMA3 [dBuV]
3) Product Takeover
Make sure that the product is not damaged. Please contact your dealer in the case of damage.
4) Product Storing and Installation
We recommend the device to be installed and serviced by the qualified technician.
The product must not be stored and installed
•
in the place with excessive humidity
• in the place with excessive dust pollution, mechanical vibrations or impacts
• in the place out of temperature limits specified in the section 2) Technical Specifications
• close to heat sources (radiators or air ventilators, direct sunshine etc.)
• in the reach of children.
Do not expose the apparatus to dripping or splashing. Use the apparatus only in moderate climates (not in
tropical climate).
Fix the product firmly on a wall or another hard and inflammable surface with screws and dowels.
• The product shall be in no case held only by the connected cables.
• Do not cover the product (with curtains etc.).
•
Do not place any containers with liquids (vases, glasses etc.) or naked flame sources (lighted
candle etc.) on the product or near the product.
5) Product connection
Connect the product in accordance with this manual and valid regulation in your country. Use high quality
75 Ω coaxial cable designed for satellite reception. Mount the F connectors (screw, crimp or compress type)
on the ends of coaxial cables. Connect the F connectors into the F sockets of product and fasten them with
an appropriate force. The coaxial cables shall not be broken, the minimum bending radius should be 5 cm.
Where appropriate it is possible to use quick Fm–Fm adapters instead of cable jumpers.
• Connect input F sockets marked A–D and TERR IN with output F sockets of preceding element of
cascade (LNB, cascadable multiswitch or amplifier).
• Connect output F sockets marked A–D and TERR OUT with input F sockets of next element of
cascade (cascadable multiswitch, amplifier or termination block).
•
Connect user outputs 1–12 (or 1–16, according to type) to suitable wall sockets.
MS5/5+12ECP5dB-4
MS5/5+12ELP5dB-4
20 dB (min) at user outputs, 25 dB (min) at trunk outputs
TERR 86 dBuV
SAT 85 dBuV
50 mA (18V) each receiver
18.2 x 15.2 x 4.5 cm
−25 – +60 °C
MS5/5+12ECP10dB-4
MS5/5+12ELP10dB-4
TERR 83 dBuV
SAT 80 dBuV
2 of 4
MS5/5+16ECP5dB-4 MS5/5+16ECP10dB-4
MS5/5+16ELP5dB-4 MS5/5+16ELP10dB-4
TERR 85 dBuV
SAT 85 dBuV
TERR 82 dBuV
SAT 80 dBuV
