Installation Guide
For Models:
PAP52ABZ5RCDI
PAP52MWW5RCDI
LISTED
For
Damp Location
E192641
net weight of fan: 31.97 lb (14.5 kg)
READ THESE INSTRUCTIONS
AND SAVE THEM FOR FUTURE USE
Table of Contents:
Safety Tips. pg. 1
Unpacking Your Fan. pg. 2
Parts Inventory. pg. 2
Installation Preparation. pg. 3
Hanging Bracket Installation. pg. 3
Fan Assembly. pgs. 4 - 5
Wiring. pgs. 5 - 6
Canopy Assembly. pg. 6
Blade Assembly. pg. 6
Wall Control Operation. pg. 7
Remote Control Operation. pg. 8
Testing Your Fan. pg. 8
Troubleshooting. pg 9
Warranty. pg. 9
Parts Replacement. pg. 9
