Comeup Seal Gen2 9.5 Manual

Winch Assembly

Introduction

 Feature
Line pull: 4,309 kg / 9,500 lb wire rope first layer
Wire rope: 8.7 mm × 30.5 m (11/32"×100') galvanized aircraft A7 × 19
Brake: Patented cone brake holds full load
Clutch: Turn the T-handle for rapid wire rope payout
Control: Handheld pendant switch powers the winch
 Unpacking
．Winch assembly................................................................... 1 pc
． Control box............................................................................. 1 pc
．Remote control.................................................................... 1 pc
．Wire rope with hook.............................................................. 1 pc
．Roller fairlead...................................................................... 1 pc
．1.8 m (6') 2 gauge battery lead............................................... 1 pc
 Read this manual carefully
You should carefully read and understand this manual before operating it.
Careless winch operation may result in personal injury hazards or property
damage.

Installation

Before using the winch, make sure all electrical components have no
corrosion or damaged; the environment
should be clear and dry.
 Winch and roller fairlead mountings
 It is very important that the winch will be
mounted on a flat and hard surface of
mounting channel in order to make sure
the motor, drum and gearbox housing are
aligned correctly.
Self-Recovery Winch
Seal Gen2 9.5
Model:
PN: 295950 12V DC
