  • Page 1 INSTALLATION AND OPERATING INSTRUCTIONS DÜRR VISTACAM, VISTACAM CL 2106 VistaCam VistaCam CL 9000- 618- 58/ 30 2004/11...
  • Page 3: Table Of Contents

    CONTENTS Important Information Use of the Appliance 10. Operation ..........17 1. Notes ............4 10.1 Switching on VistaCam and 1.1 Conformity Acceptance Procedure ... 4 VistaCam CL ........17 1.2 General Notes ........4 10.2 Operating the IFC Optic ....17 1.3 General Safety Notes ......
  • Page 4: Important Information

    • Any reprinting of the technical documentation, in whole or in part, is subject IMPORTANT to prior approval of Dürr Dental being given INFORMATION in writing. 1.3 General Safety Notes This appliance has been designed and 1. NOTES constructed by Dürr Dental so that correct usage of the appliance is virtually free of any 1.1 Conformity Acceptance Procedure possible injury or danger.
  • Page 5: Notes Concerning Medical Appliances Mpg

    1.4 Notes concerning Medical 1.7 Warnings and Symbols Appliances MPG In the Installation and Operating Instructions use is made of the following terms or symbols • This product is a technical medical to denote information of special importance: appliance and, as such, may only be operated by trained personnel, or persons Information and/or mandatory who, as a result of specialist knowledge, are...
  • Page 6: Product Information

    2. PRODUCT INFORMATION Optics cleaning set ....... 2106-150-50 Optics cleaning set ....... 2105-105-00 2.1 Correct Usage VistaCam CL (radio) for PC and Video Solutions The Dürr VistaCam has been designed Installation and Operating Instr..9000-618-58 exclusivley for the creation of intraoral and Handpiece (PAL) ......
  • Page 7: Technical Data

    4. TECHNICAL DATA Electrical Values and Connections Ambient air pressure Appliance in operation (hPa) .... 700-1060 Voltage (V) 100-240 Frequency (Hz) 50-60 Camera electronics PAL / NTSC Output (VA) Basis station Image sensor1/4" Color Interline Transfer CCD Battery charger Pixels PAL ........
  • Page 8: Functional Diagram

    5. FUNCTIONAL DIAGRAM VistaCam VistaCam CL...
  • Page 9: Functional Description

    6. FUNCTIONAL DESCRIPTION The handpiece with the lighting is VistaCam automatically switched on as soon as it is consists of a Basis station (1), the handpiece removed from its holder (2) or removed from (6) with an IFC (Iris Focus Control) Optic and the battery charger unit (5).
  • Page 10: Installation

    INSTALLATION 7. SET-UP The plug and socket where the Basis station (1) is to be connected to the mains must be easily accessible. The VistaCam must not be set up near any wash basins or the spittoon. No water, even spray, should come into contact with the appliance.
  • Page 11: Attaching The Handpiece Holder

    7.3 Attaching the handpiece holder The handpiece holder (2) can be attached directly to the Basis station or mounted at any appropriate position in the vicinity of the VistaCam (camera cable length 2 m). Use the mounting set, order number 2105- 105-00 A description of how to set up the holder is included in the Mounting Set.
  • Page 12: Electrical Connections

    8. ELECTRICAL CONNECTIONS When connecting to image viewing hardware ensure that IEC 60601-1 (EN 60 601-1; VDE 0750 Teil 1-1) is observed. If you have questions conserning suitable connections please consult your supplier or specialist. Observe the Operating Instructions for the video printer or the video monitor.
  • Page 13: Pc-Solution Vistacam

    with video monitor (with freeze frame) •Connect BNC-video cable (17) or S- video cable to Basis station (1). Connect cable (17) (the BNC-interface (11) 4 pin Mini-DIN-interface (14): see fig. 5) to the video printer or video monitor (interface port is signal input). •...
  • Page 14: Commissioning

    9. COMMISSIONING Do not put the appliance into operation immediately. It should first be allowed to warm up to room temperature, otherwise dampness in the form of condensation can accumulate, which could damage the electronic components when switching on. The appliance must not be used in any way that gives concern regarding safety! The appliance may only be operated in a safe and functional condition.
  • Page 15: Vistacam Cl

    9.2 VistaCam CL Always handle the handpiece (6) carefully. It must not be allowed to fall. Scratches or dirt on the optical lens will lead to a high loss in image quality. • Place the rechargeable battery (40) into the handpiece.
  • Page 16 Where more than one treatment unit (i.e. chair) is served or where there is radio transmission interference then using the basis station (1) and the handpiece (6) it is possible to choose a new channel. Selecting a channel from the radio-controlled foot pedal see Installation Instructions 9000-618-42/01 Connections to Basis station (1)
  • Page 17: Use Of The Appliance

    USE OF THE APPLIANCE 10. OPERATION Always handle the handpiece (6) carefully. It must not be allowed to fall. Scratches or dirt on the optical lens will lead to a high loss in image quality. 10.1 Switching on VistaCam and VistaCam CL Removal of the handpiece from its handpiece holder (VistaCam) or from the battery charger...
  • Page 18: Drawing The Disposable Protective Cover Over The

    10.3 Drawing the disposable protective cover over the IFC Optic For hygienic reasons when using the VistaCam in the intraoral area then a disposable protective cover must be used. After (single) use the disposable protective cover must be carefully peeled off and disposed of correctly.
  • Page 19: Care Of Handpiece

    With freeze frame (50) Delete images (51) Switching from Standbild (Freeze) / Livebild (52) Select save location (max.12 images) (50)+(52) Switching between full image and half frame (52) press and hold (50) short press (52) let off (50)+(51) Switching between 4 and 12 images (51) press and hold (50) short press...
  • Page 20: Cleaning

    When the VistaCam CL Optic (60) blinks six times then this signifies that the battery life is sufficient for only approximately another 5 minutes of handpiece use . Carry out the following procedure in this case: • Place the handpiece in the battery charger (min.
  • Page 21: Maintenance

    12. MAINTENANCE Only use Original Equipment Manufacturing spare parts for repairs, otherwise guarantees and warranties may be infringed. Provide for a safe and ecologically correct disposal of all replaced parts. 12.1 Changing the battery pack Only for VistaCam CL (radio) •...
  • Page 22: Trouble-Shooting

    TROUBLE-SHOOTING 13. TIPS FOR OPERATORS AND SERVICE TECHNICIAN Problem Possible cause Solution 1. Image is • The disposable protective cover • Place the disposable protective cover correctly opaque, milky is not correctly in place (see Section 10.3) • IFC Optic is dirty •...
  • Page 23: Disposal

    Problem Possible cause Solution 4. Blurred image As the camera delivers a standard • Try not to move during recording video signal, certain standards (freeze frame) (practice!), if necessary use some regarding TV-technogy must be form of support for the arm (Using video observed.
