Page 1 of 12
Operating Instructions
Pump FW-A
Page
BA_2005_1_GB_FWA
replacement for 21131/32 BA 1e/ 031101HF

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FW-A and is the answer not in the manual?

Questions and answers

Related Manuals for Bijur Delimon FW-A

Summary of Contents for Bijur Delimon FW-A

  • Page 1: Table Of Contents

    Operating Instructions Pump FW-A INDEX Page 1. General ................. 2 2. Safety ................2 – 4 Pump type ................5 Number of outlets ..............5 Inspection ................5 Kinds of drive ............... 5 Position of drive ..............5 Reservoir ................6 G Accessories .................

  • Page 2: General

    General Prior to start up, we recommend to read these operating instructions carefully as we do not assume any liability for damages and operating troubles which result from the nonobservance of these operating instructions! Any use beyond the applications described in these operating instructions is considered to be not in accordance with the product’s intended purposes.
  • Page 3 Safety (continuation) Personnel qualification and training The operating, maintaining, inspecting and erecting personnel must have the appropriate qualification for such work. Area of responsibility, competence and supervision of the personnel have to be regulated by the user. If the personnel do not have the necessary knowledge, they have to be trained and given instructions.
  • Page 4 Safety (continuation) Unauthorized conversion and manufacture of spare parts Conversion or modifications to the machine are only permitted when agreed with the manufacturer. Original spare parts and accessories authorized by the manufacturer serve to ensure safety. The use of other parts may render the liability for consequencial losses null and void.

  • Page 5: A Pump Type

    GENERAL PRODUCT CHARACTERISTICS • Multi-line pump • Output volume max. per outlet: 170 cm /h (1 suction channel) 500 cm /h (3 suction channels) • Lubricant: oil, grease, semifluid grease • Surface light grey RAL 7004 PUMP TYPE FWA NUMBER OF PUMP BODYS / NUMBER OF OUTLETS 1 Pump body / 12 outlets 1 suction channel 1 Pump body / 12 outlets 3 suction channels 2 Pump body / 24 outlets 1 suction channel...

  • Page 6: Reservoir

    RESERVOIR 30 ltr. ACCESSORIES without Level switch A level switch is available for the indication of the filling level in the reservoir. As sensor serves an ultrasonic sensor. As soon as the min. or max. level allowed has been obtained, a signal is released. With the help of a signal lamp at the reservoir, this signal can be used for the visual warning or for the control of an automatic filling facility.

  • Page 7: Application

    Application The grease pump of type FW-A is of sturdy construction so that it is suitable for central lubrication systems for heavy machinery operating under severe conditions. The pump has no valves and is therefore extremely reliable. Fig. 1 Pump with oscillating lever drive Principle of operation (fig.

  • Page 8: Installation

    Installation (fig. 1) Set the pump up vertically ans secure it. The correct direction of rotation of the pump drive shaft is shown by an arrow. Ensure that when the drive unit is connected, the direction of rotation is correct. Carefully chlean all the piping before installation, by at least tapping and blowing through, and fill it which clean grease by means of a grease gun.

  • Page 9: Maintenance

    Maintenance Dismantling the pump (Fig. 1) Unscrew the nut (5), take off the blade (4) and withdraw the scraper (3), feed screw (7) and strainer (2) from the driving bush (24). Remove the three hexagon screws (33) and remove the drive assembly from the gear unit (1). Take the driving bush (24) together with the worm wheel (25) and bevel gear (26) of the pin (23).

  • Page 10: Changing The Number Of Outlets

    Changing the number of outlets Fig. 3 Section through the pump body Putting outlets out of action To put an outlet out of action, remove the associated delivery piston by proceeding as follows: Take oput the screws (19) and remove the pump mechanism. Remove the cylinder screws (9) and the cover (10).

  • Page 11: Plates

    Plates Name plate 110 x 60 mm (75511-1531) Type plate 110 x 60 mm (75511-1321) BA_2005_1_GB_FWA Page 11 of 12 replacement for 21131/32 BA 1e/ 031101HF...

  • Page 12: Manufacturer's Declaration

    Manufacturer’s declaration This manufacturer’s declaration as to the fulfilment of the requirements according to the • EC machine guideline 98/37/EG is only valid in connection with the installation/operating instructions and the relating data sheet, both being valid for the product. Company Address Telephone...
