Operating instructions
Pump ZP5000
Page
PB_2005_2_GB_ZP5000
Advertisement
Table of Contents
Related Manuals for Bijur Delimon ZP5000
Summary of Contents for Bijur Delimon ZP5000
-
Page 1: Table Of Contents
Operating instructions Pump ZP5000 INDEX Page 1. General ................2 2. Safety ................2 – 4 A. Pump type ................4 B. Number of outlets .............. 4 C. Inspection ................4 D. Kinds of drive ..............5 E. Position of drive ..............5 F. -
Page 2: General
General Prior to start up, we recommend to read these operating instructions carefully as we do not assume any liability for damages and operating troubles which result from the nonobservance of these operating instructions! Any use beyond the applications described in these operating instructions is considered to be not in accordance with the product’s intended purposes. - Page 3 Safety (continuation) Personnel qualification and training The operating, maintaining, inspecting and erecting personnel must have the appropriate qualification for such work. Area of responsibility, competence and supervision of the personnel have to be regulated by the user. If the personnel do not have the necessary knowledge, they have to be trained and given instructions.
-
Page 4: Pump Type
Pressure range up to 160 bar Lubricant oil, grease, liquid grease Surface signal grey RAL 7004 PUMP TYPE ZP5000 NUMBER OF OUTLETS 5 outlets 8 outlets 10 (5 + 5) outlets 16 (8 + 8) outlets INSPECTION... -
Page 5: Kinds Of Drive
In case of receiving the order, we will attach particular operating instructions to the level switch with the following code: BA_20XX_X_GB_76951_6011. Application The pump ZP5000 are used for direct lubrication in multi-line systems (one delivery element per lubricating point) or as delivery pump for lubricant in progressive systems PB_2005_2_GB_ZP5000... -
Page 6: Principle Of Operation
(18) is arranged in the lubricant reservoir (3). The central lubrication pump ZP5000 can be supplied with 1 or 2 pumping units (1) installed opposite to each other with a maximum of 8 outlets each. The rate of delivery can be set infinitely from 0...0,2 cm³/stroke. -
Page 7: Principle Of Operation
Principle of operation (continuation) PB_2005_2_GB_ZP5000 Page 7 of 10... -
Page 8: Specification
Specification Rated pressure ............................. 160 bar Max operating pressure : .. in dependence on operating mode and operating conditions (to be agreed upon ............................with the manufacturer) Rate of delivery per outlet ....................0 ... 0.2 cm³/stroke Pipe connection for feed line ......................M 14 x 1.5 Step-down ratio .................. -
Page 9: Specification
Specification (continuation) PB_2005_2_GB_ZP5000 Page 9 of 10... -
Page 10: Start-Up
For the first commissioning of the pumps, it is essential to fill in addition to the lubricant tank also the pump case with the lubricant to be delivered. The pump ZP5000 are provided with a conical head lubrication nipple A R1/8 DIN 71412 with the help of which this can be realized easily. The pump with pumping mechanism, one can also make filling by removing the blind flange.
