Westomatic EVOLVE Manual

Adjusting water/ flavour dispense volume
Hide thumbs Also See for EVOLVE:

Advertisement

Quick Links

Download this manual
ADJUSTING WATER/FLAVOUR
DISPENSE VOLUME

Advertisement

loading
Need help?

Need help?

Do you have a question about the EVOLVE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Westomatic EVOLVE

Summary of Contents for Westomatic EVOLVE

  • Page 1 ADJUSTING WATER/FLAVOUR DISPENSE VOLUME...
  • Page 2 S E T T I N G F L O W R A T E F A C T O R Y D E F A U L T S E T T I N G = 5 0 0 M L I N 2 3 . 5 S F L O W R A T E = 2 1 .
  • Page 3 ADJUSTING WATER DISPENSE VOLUME Equipment Needed: Measuring Jug (Min 1 litre)
  • Page 4 U S I N G T H E B U T T O N S Button 1 = UP Button 2 = DOWN Button 3 = CANCEL Button 4 = ENTER When needed to enter a passcode (Service Mode): Button 1 = 1 Button 2 = 2 Button 3 = 3 Button 4 = 4...
  • Page 5 1 - A D J U S T S E T T I N G S U S I N G L C D Open Door In DOOR OPEN mode Scroll down to SERVICE MODE Using Button 4 -ENTER Using the buttons Enter code 3211...
  • Page 6 Scroll down to DRINKS Using button 4 - ENTER Scroll down to PROTEINS Using button 4 - ENTER...
  • Page 7 Scroll down Protein Flavour Using button 4 - ENTER Scroll down to DRINK SETUP Using button 4 - ENTER...
  • Page 8 Scroll down to MAIN WATER Using button 4 - ENTER Scroll down to BOTTLE FILL Adjust the time to reflect 14.5secs is approx 300ml Using button 4 - ENTER Using button 3 - EXIT OUT & SAVE...
  • Page 9 2 - A D J U S T I N G W A T E R F I L L P R E S S U R E If the water pressure needs adjusting The Pressure Regulator is located at the back of the machine Pull cap on regulator out then turn Clockwise = INCREASES Volume...
  • Page 10 ADJUSTING FLAVOUR DISPENSE VOLUME Equipment Needed: Measuring Jug (Min 1 litre) Gram Scale...
  • Page 11 S E T T I N G G R A M T H R O W S PROTEIN SET UP: Protein recipe is water throw and flavour shot. Water throw is calculated using the equation previous. Flavour shot - each dry mix powder has a different flow rate so cannot be predetermined. Begin with a 5.0 second test throw time for the flavour.
  • Page 12 U S I N G T H E B U T T O N S Button 1 = UP Button 2 = DOWN Button 3 = CANCEL Button 4 = ENTER When needed to enter a passcode (Service Mode): Button 1 = 1 Button 2 = 2 Button 3 = 3 Button 4 = 4...
  • Page 13 1 - A D J U S T S E T T I N G S U S I N G L C D Open Door In DOOR OPEN mode Scroll down to SERVICE MODE Using Button 4 -ENTER Using the buttons Enter code 3211...
  • Page 14 Scroll down to DRINKS Using button 4 - ENTER Scroll down to PROTEINS Using button 4 - ENTER...
  • Page 15 Scroll down Protein Flavour Using button 4 - ENTER Scroll down to DRINK THROWS Using button 4 - ENTER...
  • Page 16 Scroll down to FLAVOUR SHOT Using button 4 - ENTER Scroll down to BOTTLE FILL Adjust the time to reflect 14.5secs is approx 300ml Using button 4 - ENTER Using button 3 - EXIT OUT & SAVE...
  • Page 17 RECOVER. REPEAT. CONTACT + 4 4 ( 0 ) 1 6 2 6 3 2 3 1 0 0 W e s t o m a t i c V e n d i n g S e r v i c e s L t d , s a l e s @ w e s t o m a t i c .
