REPLACE SCREEN FASCIA

Advertisement

loading
Need help?

Need help?

Do you have a question about the EVOLVE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Westomatic EVOLVE

Summary of Contents for Westomatic EVOLVE

  • Page 1 REPLACE SCREEN FASCIA...
  • Page 2 REPLACE SCREEN FASCIA Equipment Needed: 7mm Hex Socket Wrench Phillips screwdriver...
  • Page 3 D O O R L O O M / E A R T H W I R E F L U S H C O V E R D I G I T A L M E D I A S C R E E N L C D S C R E E N C O V E R L I G H T B O X / D E C A L S B O T T L E S T A T I O N L O O M S...
  • Page 4 1 - R E M O V E L I G H T B O X Unscrew washers Remove menu LED loom Remove Lightbox...
  • Page 5 2 - R E M O V E B U T T O N S Disconnect Looms x 4 Unscrew Washer x 4 Remove Button from Front...
  • Page 6 3 - R E M O V E L C D C O V E R Remove Cover and disconnect Loom...
  • Page 7 4 - U N P L U G D I G I T A L M E D I A S C R E E N Unplug power cable from digital media screen...
  • Page 8 5 - R E M O V E F L U S H C O V E R Unscrew Cover Remove Cover Unplug Loom...
  • Page 9 6 - U N P L U G M A I N B O A R D Disconnect looms as shown...
  • Page 10 7 - D I S C O N N E C T C O N V E R T O R Loosen screws Remove connectors...
  • Page 11 8 - U N P L U G F R A M E Unplug Loom Remove Earth Cable Unplug Looms...
  • Page 12 9 - R E M O V E M E T A L F R A M E Remove Frame Bolts...
  • Page 13 1 0 - U N B O L T S C R E E N P A C K E R S Unbolt Screen Packers and remove - loosen middle bottom bolt but leave in place...
  • Page 14 1 1 - R E P L A C E F A S C I A Remove plastic from back and front (keep front plastic) Slide fascia between bottom screen packer - bolt back in Replace all screen packers and bolt back into place...
  • Page 15 1 2 - R E P L A C E M E T A L F R A M E Replace Frame Bolts - ensure all looms are free of frame...
  • Page 16 1 3 - R E P L A C E D O O R C A B L E S Plug in Loom Reattach Earth Cable Plug Looms back into frame...
  • Page 17 1 4 - R E C O N N E C T C O N V E R T O R Attach Connectors Tighten Screws...
  • Page 18 1 5 - P L U G M A I N B O A R D I N Connect looms as shown...
  • Page 19 1 6 - R E P L A C E F L U S H C O V E R Attach Loom Replace Cover Replace Screws...
  • Page 20 1 7 - P L U G I N D I G I T A L M E D I A S C R E E N Plug in power cable from digital media screen...
  • Page 21 1 8 - R E P L A C E L C D C O V E R Connect Loom and replace cover...
  • Page 22 1 9 - R E P L A C E B U T T O N S Replace button from front Screw Washers on x 4 Reconnect Looms x 4...
  • Page 23 2 0 - R E P L A C E L I G H T B O X Replace Lightbox Screw washers on Replace menu LED loom...
  • Page 24 RECOVER. REPEAT. CONTACT + 4 4 ( 0 ) 1 6 2 6 3 2 3 1 0 0 W e s t o m a t i c V e n d i n g S e r v i c e s L t d , s a l e s @ w e s t o m a t i c .
