- Page 1 FITTING PLINTHS...
- Page 2 FITTING PLINTHS Equipment Needed: 8mm Hex Socket Wrench Phillips screwdriver...
- Page 3 I N S I D E T H E M A C H I N E P L I N T H S...
- Page 4 1 - U N P A C K P L I N T H S Plinths will have bolts fitted The bolts must be located closer to the bottom when fitting The bolts fit into a keyhole connection with the front plinth...
- Page 5 2 - F I T S I D E P L I N T H S Remove screws Fit plinth to front Slide plinth into back Replace screws of machine first Repeat steps on other side...
- Page 6 3 - F I T F R O N T P L I N T H Remove countersink Replace screws x2 screws x2 Ensure plinth and Plinths fitted on both countersink align sides and front...
