INSTRUCTION MANUAL
Automatic Spray Guns
Be sure to observe warning s and cautions in this instruction manual.
If not, it can cause paint ejection and serious bodily injury by drawing organic solvent.
Be sure to observe following marked items which are especially important.
Indicates a potentially hazardous situation which, if not avoided, may result in serious injury or loss
of life.
Indicates a potentially hazardous situation which, if not avoided, may result in minor
or moderate injury or property damage.
Indicates notes which we ask you to observe.
instruction manual are the minimum necessary conditions.
local regulations regarding fire prevention, electricity and safety as well as your own
company regulations.
Symbol Marking
on the Spray Gun:
This ANEST
IWATA spray gun
complies with
Complies
2014/34/EU
with
Directive relating to
European
equipment and
Directive
protective systems
intended for use in
explosive
potentially
atmospheres.
Important specifications
Max. Pressure
0.70MPa / 7.0bar / 100psi
83dB(A)
Noise level
Spray condition Recommended
Measuring point 1m backwards from spray gun, 1.6m height
Max. temperature Atmosphere: 5°C ~40°C (41°F~104°F)
Main specifications
Nozzle orifice
Type of
Model
feed
Φ mm (in)
WIDER1A-08E2P 0.8 (0.031)
WIDER1A-10E2P 1.0 (0.039)
WIDER1A-10E1 1.0 (0.039)
WIDER1A-13H2 1.3 (0.051)
WIDER1A-15H2 1.5 (0.059)
WIDER1A-05R 0.5 (0.020)
WIDER2A-12G2P 1.2 (0.047)
WIDER2A-15K2 1.5 (0.059)
WIDER2A-20R2 2.0 (0.079)
WIDER2A-25W1 2.5 (0.098)
*1. Atomizing air pressure means air pressure at spray gun inlet when trigger is pulled and air flows.
II 2 G Ex h X
II 2
Specific Group II Category
Marking for (Surface) (Zone 1&2)
Explosion
Protective
Recommended condition
Air cap assy
*1 Atomizing air pressure
Mark
MPa (bar / PSI)
E2P
E1
H2
0.29 (2.9/43)
05R
G2P
K2
R2
W1
The safety precautions in this
Follow national and
G Ex h
Type of Ignition
Atmospher Protection
e (not applied)
(GAS)
Air and Fluid: 5°C ~43°C (41°F~109°F)
Air consumption
Fluid output
l/min (cfm)
ml/min
150
270 (9.5)
200
100 90 (3.2)
250
260 (9.2)
270
20 40 (1.4)
500 530 (18.7)
270 330 (11.7)
400 360 (12.7)
500 360 (12.7)
- 1 -
This manual contains IMPORTANT WARNINGS and
INSTRUCTIONS.
Equipment in this manual is exclusively for painting
purposes.
Do not use for other purposes.
The operator shall be fully conversant with the
requirements stated in this instruction manual
including important warnings, cautions and operation
and correct handling.
Read and understand the instruction manual, before
use and retain for reference.
IIB T6 Gb
Explosion Temperatur Explosion
Group e Class Protection
(Ethylene) (≤ 85°C) level
(EPL)
Nozzle needle assy combination
Orifice Φ
Model
mm (in)
Φ0.5
Φ0.8
WIDER1A
Φ1.0
Φ1.3
Φ1.5
Φ1.2
Φ1.5
WIDER2A
Φ2.0
Φ2.5
Pattern width
Air & fluid connection
mm (in)
190 (7.5)
220 (8.7)
140 (5.5)
Atomizing air:Φ8
230 (9.1)
Operation air:Φ6
255 (10.0)
35 (1.4)
400 (15.7)
WIDER1A:G1/4
340 (13.4)
WIDER2A:G3/8
320 (12.6)
330 (13.0)
X T
Amb
+5°C +40°C
Additional Ambient
conditions: Temperatu
re
Any static
Electricity
should be
discharged
and needs to
be diverted to
the ground via
a conductive
air hose not
included.
Fluid nozzle
Fluid needle
Mark
Mark
05H WIDER1A
/ W1 / 05
/ W1 / 08
12H WIDER1A
/ W1 / 10
/ W1 / 13
15H WIDER1A
/ W1 / 15
/ W2 / 12 12H WIDER1A
/ W2 / 15 15H WIDER1A
/ W2 / 20 20H WIDER2A
/ W2 / 25 25H WIDER2A
Mass
g (lbs.)
【Air】
400
(0.88)
【Fluid】
420
(0.93)
