Instructions: QUATTRO
QUATTRO BED
(Version Nov 2021)
FRAME
Assembly Instructions
(All Sizes)
IMPORTANT – READ CAREFULLY –
RETAIN FOR FUTURE REFERENCE
CUSTOMER CARE
We have checked all parts to ensure they are free of damage. However timber is a natural, living product.
Occasionally timber can still be adjusting to humidity, for this reason a crack or stretch mark may appear after
the product has been packaged.
Strictly Beds and Bunks however have a FREE PARTS REQUEST
service in this unlikely event. You need to order a part please go to
Parts Portal - www.strictlyhelpdesk.co.uk.
Email Assistance: help@strictlybedsandbunks.co.uk
Using the Camera on your phone scan this barcode to
take you our after sales. You can find various options as
regards assistance on this purchase.
Mattress Selection Available
Strictly Beds has a full range of mattresses to fit this bunk bed.
To go to our selection please type in
www.strictlbedsandbunks.co.uk/mattress
Using the Camera on your phone, scan this barcode to
take you to our mattress selection
IMPORTANT: DO NOT DISPOSE of
the packaging until you are satisfied
with your purchase.. Please keep all
cardboard until fully satisfied.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Strictly Beds & Bunks QUATTRO BED FRAME
Summary of Contents for Strictly Beds & Bunks QUATTRO BED FRAME
- Page 1 Single Size Kit B Double Size Kit A (Plus Quattro K2) Instructions: QUATTRO QUATTRO BED (Version Nov 2021) FRAME Assembly Instructions (All Sizes) IMPORTANT – READ CAREFULLY – RETAIN FOR FUTURE REFERENCE CUSTOMER CARE We have checked all parts to ensure they are free of damage. However timber is a natural, living product. Occasionally timber can still be adjusting to humidity, for this reason a crack or stretch mark may appear after the product has been packaged.
- Page 2 TOP TIPS - TOP TIPS Read before you start assembly Locating the Dowel Rods To keep the bed from rattling all the dowel holes have been slightly mis-drilled by a couple of mm. When you push parts together the dowels will straighten and pull together to ensure a tight fit.
- Page 3 Using the Camera on your phone scan this barcode to take you our after sales. You can find various options as regards assistance on this purchase.
- Page 4 Parts Identifier Description Part Q1 Quattro Corner Post ( HB Left) Part 25- Siderail Support Legs Part Q2 Quattro Corner Post (HB Right) Part 26- Centre Leg (Not Single Size) Part Q3 Quattro Corner Post (FB Left) Part 9- (4G) Shaker headboard Insert Part Q4 Quattro Corner Post (FB Right) Part 13- Double Blue headboard facia Part 1 - LONG Side Rail...
- Page 5 How to identify your parts and fixings BLUE MARKING/FIXINGS **SINGLE BEDS ONLY** The part will have a blue marker pen marking on the end. Hole / Bolt configuration: TWO large dowel holes - Place for large dowel One small centre hole - Place for large 90mm connector bolt D BLUE MARKING/FIXINGS ** DOUBLE/KING BEDS ONLY** The part will have a blue marker pen marking on the end.
- Page 6 First Build the Head Board Insert Place dowel rods in all the headboard inserts as described, DO NOT PUSH ALL THE WAY IN. Now locate the PART 9 facias and push in to create the headboard. The dowels will straighten as they align.
- Page 7 Attach the two side rails Firstly ensure there is no sawdust or debris in the access holes. Using a bolt push through to clear. Now insert the dowel rods at all ends, do not push all the way in. Make sure the WHITE MARKINGS on each headboard are facing inwards. Now start with the headboard and connect each side rail to each corner post Place the barrel bolt within the round access hole on the side rail.
- Page 8 Attach The Centre Rail (Double/Kingsize Beds ONLY) From the inside of the bed we need to attach metal brackets, one either end. These are fixed using the small screws (L), these are fixed to bottom headboard facia. Using a tape mark a centre line from each corner post, then measure and mark 55mm from the top of the BLUE Facia(13).
