Box D
Instructions 18
(revised September 2020)
Assembly Instructions
DUKE Triple Bunk Bed
IMPORTANT – READ CAREFULLY –
RETAIN FOR FUTURE REFERENCE
Assembly Instruction
Safety First !
The top surface of the mattress must not be above the line ,marked on the frame (Maximum height:
20cm). The size of the mattress required is detailed below:
Top Bunk - Mattress size 90cm by 190cm
Bottom Bunk:
If 4ft double Mattress size 120cm by 190cm
If 4ft 6 double - Mattress size 135cm by 190cm
High beds and the upper bed of a bunk bed are not suitable for children under six years due to risk
of injury from falls.
Be aware of the danger of young children (under 6) falling from upper bunk.
Beds should not be used if any structural part is broken or missing.
Bunk beds and high beds can present a serious risk of injury from strangulation if not used
correctly. Never attach or hang items to any part of the bunk bed that are not designed to be used
with the bed, for example, but not limited to ropes, strings, cords, hooks, belts and bags.
Children can become trapped between the bed and the wall, a roof pitch, the ceiling, adjoining
pieces of furniture (eg cupboards) and the like. To avoid risk of serious injury the distance between
the top safety barrier and the adjoining structure shall not exceed 75mm or shall be more than
230mm.
Always ensure that guardrails, ladder and other components are maintained in the proper position
and free from damage, and all the screw fixings tight.
Always use the ladder for entering and leaving the upper bunk.
Do not allow horseplay on or under the bed and prohibit jumping on the bed.
Use a nightlight as an added safety precaution for persons under the upper bunk.
Use guardrails on both sides of the upper bunk.
Every bedroom must have at least one opening window. Ventilation of the room is necessary in
order to keep the humidity low and to prevent mould in and around the bed.
The bed complies with BS EN 747-1: 2012+A1 :2015 safety standards
Advertisement
Related Manuals for Strictly Beds & Bunks DUKE Triple Bunk Bed
Summary of Contents for Strictly Beds & Bunks DUKE Triple Bunk Bed
- Page 1 Box D Instructions 18 (revised September 2020) Assembly Instructions DUKE Triple Bunk Bed IMPORTANT – READ CAREFULLY – RETAIN FOR FUTURE REFERENCE Assembly Instruction Safety First ! The top surface of the mattress must not be above the line ,marked on the frame (Maximum height: 20cm).
- Page 2 TOP TIPS - TOP TIPS Read before you start assembly Locating the Dowel Rods To keep the bed from rattling all the dowel holes have been slightly mis-drilled by a couple of mm. When you push parts together the dowels will straighten and pull together to ensure a tight fit.
- Page 3 How to identify your parts and fixings All our products have four attachment methods. These are colour coded, at the end of each part you will find a marker pen marking either RED, WHITE or BLUE (two types) RED MARKING/FIXINGS The part will have a red marker pen marking on the end.
- Page 4 Packing Note: BOX ONE Packing Note: BOX TWO Description Required Part 1- Long Side rail Part 2- Red Top Long Back Guard Rail BL - Corner Post - Back Left Part 3- Bottom Long Back Guard Rail BR - Corner Post - Back Right Long Centre Rail (190cm) 4'6 - Triple Sleeper Cross Bar 4E Bespoke Centre Rail (186cm)
- Page 5 Fixing List Note: The quanitities below are the correct amount to complete the assembly. In some cases more fittings may be suppplied than required. Fixing A1 Fixing H Small sachet of glue for 90mm ladder silver hook bolts B & C (NOT dowels) To connect ladder to bunk Number Required Number required...
- Page 6 The ladder on this model goes at the end of the bed. So you need to choose which end you require this ladder to go, left or right. Which ever end you choose the ladder to go on DO NOT add the RED and WHITE head board inserts.
- Page 7 Lets Build the right hand side headboard First we need to assemble the headboards. We will start by building the left headboard. You will need the following parts: BL - Back left Corner Post 4C - Red Top Headboard Facia 4B - White Middle Headboard facia 4D - Blue Bottom Headboard facia MR - Middle Right Corner Post...
- Page 8 Now two people are required for this. We are now attaching the Front back guard rails and side rails. Ensure the white chalk markings are facing inside the bed. From the top of the picture you need to find and attach the following: Top Guard Rail - RED - Part 2 x 2 Bottom Guard Rail - WHITE - Part 3 x 2 Side rail - Universal - Part SR x 1...
- Page 9 Attach the Mini Headboards to the ladder end. We need to locate the mini facias at the ladder end parts E10 (red- Top) and E09 (white) at the ladder end. Part E10 uses one dowel and bolt BLUE D. Part E09 uses two dowels. We now build the ladder You will have two ladder struts, these need to be connected to the ladder.
- Page 10 Attaching the ladder to the bed. Push the ladder to the headboard in and hook over the top blue headboard facia. Centre the ladder so both the ends of Part E10 and E09 meet the struts. This should be a gap of 79cm from each corner post.
- Page 11 Now attach Centre Rail, Base Slats and Guard Rail Supports (See colour leaflet for instructions) The centre leg is located under the centre rail, in the centre. Simply measure to the centre of the bed and locate under the centre rail. Using two black screws attach from the side.
- Page 12 Attach Centre Rail & Base slats Now attach the centre rail You will find two metal brackets, these are fixed to the bottom facia on the head and foot boards (blue). With a tape measure mark the centre of the headboard facia. Using the small screws attach to the bottom of the facia board.
