Box D
Instructions 17
(revised September 2020)
Assembly Instructions
DUCHESS Triple Bunk Bed
IMPORTANT – READ CAREFULLY –
RETAIN FOR FUTURE REFERENCE
Assembly Instruction
Safety First !
The top surface of the mattress must not be above the line ,marked on the frame (Maximum height:
20cm). The size of the mattress required is detailed below:
Top Bunk - Mattress size 90cm by 190cm
Bottom Bunk:
If 4ft double Mattress size 120cm by 190cm
If 4ft 6 double - Mattress size 135cm by 190cm
High beds and the upper bed of a bunk bed are not suitable for children under six years due to risk
of injury from falls.
Be aware of the danger of young children (under 6) falling from upper bunk.
Beds should not be used if any structural part is broken or missing.
Bunk beds and high beds can present a serious risk of injury from strangulation if not used
correctly. Never attach or hang items to any part of the bunk bed that are not designed to be used
with the bed, for example, but not limited to ropes, strings, cords, hooks, belts and bags.
Children can become trapped between the bed and the wall, a roof pitch, the ceiling, adjoining
pieces of furniture (eg cupboards) and the like. To avoid risk of serious injury the distance between
the top safety barrier and the adjoining structure shall not exceed 75mm or shall be more than
230mm.
Always ensure that guardrails, ladder and other components are maintained in the proper position
and free from damage, and all the screw fixings tight.
Always use the ladder for entering and leaving the upper bunk.
Do not allow horseplay on or under the bed and prohibit jumping on the bed.
Use a nightlight as an added safety precaution for persons under the upper bunk.
Use guardrails on both sides of the upper bunk.
Every bedroom must have at least one opening window. Ventilation of the room is necessary in
order to keep the humidity low and to prevent mould in and around the bed.
The bed complies with BS EN 747-1: 2012+A1 :2015 safety standards
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Strictly Beds & Bunks DUCHESS Triple Bunk Bed
Summary of Contents for Strictly Beds & Bunks DUCHESS Triple Bunk Bed
- Page 1 Box D Instructions 17 (revised September 2020) Assembly Instructions DUCHESS Triple Bunk Bed IMPORTANT – READ CAREFULLY – RETAIN FOR FUTURE REFERENCE Assembly Instruction Safety First ! The top surface of the mattress must not be above the line ,marked on the frame (Maximum height: 20cm).
- Page 2 TOP TIPS - TOP TIPS Read before you start assembly Locating the Dowel Rods To keep the bed from rattling all the dowel holes have been slightly mis-drilled by a couple of mm. When you push parts together the dowels will straighten and pull together to ensure a tight fit.
- Page 3 How to identify your parts and fixings All our products have four attachment methods. These are colour coded, at the end of each part you will find a marker pen marking either RED, WHITE or BLUE (two types) RED MARKING/FIXINGS The part will have a red marker pen marking on the end.
-
Page 4: Customer Care
You will find within the following instructions guidance on how to build this bunk bed. Please note this is a solid product. Each part needs fixing separately as described, however with patience you will, have a solid, long lasting bed. Summary of installation: 1. - Page 5 Fixing List Note: The quanitities below are the correct amount to complete the assembly. In some cases more fittings may be suppplied than required. Fixing A1 Fixing H Small sachet of glue for 90mm ladder silver hook bolts B & C (NOT dowels) To connect ladder to bunk Number Required Number required...
- Page 6 Lets Build the left hand side headboard First we need to assemble the headboards. We will start by building the left headboard. You will need the following parts: BR - Back Right Corner Post 4C - Red Top Headboard Facia 4B - White Middle Headboard facia 4D - Blue Bottom Headboard facia ML - Middle Left Corner Post...
- Page 7 Lets Build the right hand side headboard First we need to assemble the headboards. We will start by building the left headboard. You will need the following parts: BL - Back left Corner Post 4C - Red Top Headboard Facia 4B - White Middle Headboard facia 4D - Blue Bottom Headboard facia MR - Middle Right Corner Post...
- Page 8 Now two people are required for this. We are now attaching the back guard rais and side rails. Ensure the white chalk markings are facing inside the bed. From the top of the picture you need to find and attach the following: Top Guard Rail - RED - Part 18 x 1 Bottom Guard Rail - WHITE - Part 15 x 1 Siderail - Universal - Part SR x 1...
- Page 9 Now we are to attach the front guard rails and First decide what side you want the ladder, left or right. If you want the ladder to the left hand side measure 40cm from the left corner post and mark a line in pencil on the side rail.
- Page 10 Now we need to build the ladder and attach You will find The ladder consists two hooks. of two ladder struts Using the small and ladder rungs. screw attach Position these as per these to the the picture opposite inside of the two slanted ladder struts.
- Page 11 Now attach the base slats, centre and guard rail supports (Directions can be found in attached colour supplement) The centre leg is located under the centre rail, in the centre. Simply measure to the centre of the bed and locate under the centre rail. Using two black screws attach from the side.
- Page 12 Attach Centre Rail & Base slats Now attach the centre rail You will find two metal brackets, these are fixed to the bottom facia on the head and foot boards (blue). With a tape measure mark the centre of the headboard facia. Using the small screws attach to the bottom of the facia board.
