Instructions 23
Box A
Assembly
Instructions
Athens Double/Kingsize Bed
Assembly Instructions
IMPORTANT – READ CAREFULLY –
RETAIN FOR FUTURE REFERENCE
DO NOT DISPOSE
IMPORTANT:
of the packaging until you
are satisfied with your purchase.
We have checked all parts to ensure they are free of damage. However timber is a
natural, living product. Occasionally timber can still be adjusting to humidity, for this
reason a crack or stretch mark may appear after the product has been packaged.
Strictly Beds and Bunks however have a
FREE PARTS REQUEST
service in this unlikely event. You need to order a part please go to our FREE help
desk www.strictlyhelpdesk.co.uk.
Assistance: help@strictlybedsandbunks.co.uk
Advertisement
Table of Contents
Related Manuals for Strictly Beds & Bunks Athens Double/Kingsize Bed
Summary of Contents for Strictly Beds & Bunks Athens Double/Kingsize Bed
- Page 1 Instructions 23 Box A Assembly Instructions Athens Double/Kingsize Bed Assembly Instructions IMPORTANT – READ CAREFULLY – RETAIN FOR FUTURE REFERENCE DO NOT DISPOSE IMPORTANT: of the packaging until you are satisfied with your purchase. CUSTOMER CARE We have checked all parts to ensure they are free of damage. However timber is a natural, living product.
- Page 2 TOP TIPS - TOP TIPS Read before you start assembly Locating the Dowel Rods To keep the bed from rattling all the dowel holes have been slightly mis-drilled by a couple of mm. When you push parts together the dowels will straighten and pull together to ensure a tight fit.
- Page 3 How to identify your parts and fixings All our products have four attachment methods. These are colour coded, at the end of each part you will find a marker pen marking either RED, WHITE or BLUE (two types) RED MARKING/FIXINGS The part will have a red marker pen marking on the end.
- Page 4 Packing Note: Box 1 of 1 Athens Double/Kingsize Description Required Part BS- Pack of 12x Base Slats Part 1 - LONG Side Rail Part 16- LONG Centre Rail Part 9- Headboard Insert (4G) Part AL - Left Headboard Corner Post Part AR - Right Headboard Corner Post Part STR - Right footboard Corner Post Part STL - Left footboard Corner Post...
- Page 5 CUSTOMER CARE We have checked all parts to ensure they are free of damage. However timber is a natural, living product. Occasionally timber can still be adjusting to humidity, for this reason a crack or stretch mark may appear after the product has been packaged.
- Page 6 Build the headboards PIC 1 - First Select the top headboard posts. These will be marked AL ( lay on the left side) and AR (lay on the right side). IMPORTANT: These posts will have a white chalk marking, Pic 1 these MUST be facing you and at the top when laying on the carpet.
- Page 7 Attach the side rail support legs It is important this leg is attached as it supports the side rail. Measure a half way point on the side rail. Place the support leg under the side rail from the outside. Using two black screws attach from the inside of the side rail.
