Technical data
Numerical line differential protection SIPROTEC 7SD600 V3.0
Table 3.1 General device data
Serial interface
Standard
Test voltage
Connections
Transmission speed
Table 3.2 Mechanical details
Mechanical details Housing
Dimensions
Weight
Protection class to EN 60529
3 - 2
in housing for panel surface mounting
in housing for control panel/cubicle mounting
housing
terminals
System manual Order no. E50417-G1176-C069-A1
isolated
RS485
3.5 kV-
via conductor to housing terminals, two lines
for data, 1 earthing cable, for connection of a
PC or similar device lines must be shielded,
shield must be earthed.
Pre-setting 9600 baud
min. 1200 baud; max. 19200 baud
7XP20; see section 2.1
see section 2.2
approx. 4.5 kg
approx. 4 kg
IP 51
IP 21
