- Page 1 11211722V COMPUTER DESK...
-
Page 2: Parts And Hardware
PARTS AND HARDWARE BEFORE YOU BEGIN, PLEASE FOLLOW ASSEMBLY INSTRUCTIONS CAREFULLY. FOLLOW THEM STEP BY STEP. LONG TUBE (2 PCS) SHORT TUBE (12 PCS) LEG (4 PCS) INSERT CAP (4 PCS) (2 PCS) DRAWER SLIDE (1 SET) (2 PCS) 10mm SCREW ( 9 PCS) 32mm SCREW (4 PCS) L-BRACKET (1 PCS) A TOP PANEL (1 PC) -
Page 3: Phillips Screwdriver
BEFORE YOU BEGIN, PLEASE READ ASSEMBLY INSTRUCTIONS CAREFULLY. FOLLOW THEM STEP BY STEP. CAUTION : 1. ADULT SUPERVISION IS REQUIRED DUE TO SMALL PARTS. CARE SHOULD BE TAKEN IN THE UNPACKING AND ASSEMBLY OF THE PRODUCT. 2. ASSEMBLE ON SOFT SURFACES TO PREVENT DAMAGE TO THE PRODUCT FINISH. - Page 4 STEP 1. ATTACH THE INSERT CAPS ( 4 ) TO THE TOP PANEL ( A ) USING 4 SHORT TUBES ( 2 ) AS SHOWING. UNFINISHED SURFACE...
- Page 5 STEP 2. ATTACH 10" DRAWER SLIDERS ( 5A ) TO L & R SLIDER PANEL ( D ) USING 1/2" SCREWS ( 6 ) AS SHOWN. UNFINISHED EDGE UNFINISHED EDGE...
- Page 6 STEP 3. ATTACH F & B APRON PANEL ( C ) TO ASSEMBLED L & R SLIDE PANEL ( D ) FROM STEP 2 USING 32mm SCREWS ( 7 ) AS SHOWN. UNFINISHED SURFACE UNFINISHED EDGE UNFINISHED SURFACE...
- Page 7 STEP 4. USING THE ASSEMBLED PARTS FROM STEP 1 AND STEP 3 ATTACH SHORT TUBES ( 2 ) AS SHOWN. UNFINISHED SURFACE UNFINISHED SURFACE...
- Page 8 STEP 5. ATTACH L & R SIDE PANEL ( F ) AND BOTTOM CROSSBAR ( G ) TO ASSEMBLED FROM STEP 4 USING LONG TUBES ( 1 ) AND SHORT TUBES ( 2 ) AS SHOWING. UNFINISHED SURFACE UNFINISHED SURFACE UNFINISHED SURFACE...
- Page 9 STEP 6. ATTACH BOTTOM PANEL ( P2 ) TO ASSEMBLED FROM STEP 5 USING LEGS ( 3 ) AS SHOWING. UNFINISHED SURFACE...
- Page 10 STEP 7. ATTACH 10" DRAWER SLIDERS (5B) AND TO KEYBOARD PANEL (C) USING 1/2" SCREWS (6) AS SHOWN. UNFINISH SURFACE FINISH EDGING SURFACE...
- Page 11 STEP 8. ATTACH L-BRACKET (8) TO KEYBOARD PANEL (C) USING 1/2" SCREWS (6) AS SHOWN. FINISH SURFACE...
- Page 12 STEP 9. SLIDE THE KEYBOARD PANEL ( C ) TO THE ASSEMBLED COMPUTER DESK AS SHOWN. 150 lbs. This unit is intended for use only with the products and maximum weights indicated. Use with other products or products heavier than the maximum weights indicated may result in instability causing possible injury.
