FourStarGroup MS 39-084-006-61 Assembly Instructions Manual

Side table
Hide thumbs

Advertisement

Quick Links

Download this manual
ITEM: MS 39-084-006-61
UPC# 049696120593
STOP
Do you have any questions? Missing small parts or hardware?
If you need assistance with the assembly of your SIDE TABLE
please e-mail our Customer Service Department at:
support@fourstari.com or call us at 1-800-639-3803
Please let customer service know:
1. You purchased this item from Wal-Mart
2. The item description is: SIDE TABLE
3. The item number is MS 39-084-006-61
4. The part number/letter and quantity needed
If you have this information ready, we will be able to process
your request promptly. Thank you
LOT#0000-00000 DATE PURCHASED________________
THIS INSTRUCTION MANUAL CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
THIS INSTRUCTION MANUAL IS PRINTED ON RECYCLED PAPER
USING EARTH FRIENDLY SOY BASED INK.
SIDE TABLE
Do not return to the store
MODEL: MS 39-084-006-61
/
/

Advertisement

loading
Need help?

Need help?

Do you have a question about the MS 39-084-006-61 and is the answer not in the manual?

Questions and answers

Related Manuals for FourStarGroup MS 39-084-006-61

Summary of Contents for FourStarGroup MS 39-084-006-61

  • Page 1 1. You purchased this item from Wal-Mart 2. The item description is: SIDE TABLE 3. The item number is MS 39-084-006-61 4. The part number/letter and quantity needed If you have this information ready, we will be able to process your request promptly.

  • Page 2: Phillips Screwdriver

    CAUTION : 1. Read this instruction manual and keep it for reference. 2. Adult supervision is required due to small parts. 3. Assemble on soft surfaces to prevent damage to the product finish. 4. Recommended two people to assemble the product. 5.

  • Page 3: Parts And Hardware

    PARTS AND HARDWARE BEFORE YOU BEGIN, PLEASE FOLLOW ASSEMBLY INSTRUCTIONS CAREFULLY. FOLLOW THEM STEP BY STEP. Part Name Line-art Drawing Size Quantity Material Finish Leg Frame 71 x 30 cm Metal Silver Wire Shelf 38 x 29.5 cm Metal Silver Top Panel 45.7 x 33 x 1.2 cm Black...
  • Page 4 ASSEMBLY INSTRUCTIONS Step 1. Attach WIRE SHELF (B) to each LEG FRAME (A) using 30MM BOLTS (2) and PLASTIC WASHERS (D) as shown. B Wire Shelf - 1 PC D Plastic Washer - 4 PCS 2 30mm Bolt - 4 PCS...
  • Page 5 Step 2. Repeat STEP 1. Attach WIRE SHELF (B) to each LEG FRAME (A) using 30MM BOLTS (2) and PLASTIC WASHERS (D) as shown. B Wire Shelf - 1 PC D Plastic Washer - 4 PCS 2 30mm Bolt - 4 PCS...
  • Page 6 Step 3. Repeat STEP 1. Attach WIRE SHELF (B) to each LEG FRAME (A) using 30MM BOLTS (2) and PLASTIC WASHERS (D) as shown. B Wire Shelf - 1 PC D Plastic Washer - 4 PCS 2 30mm Bolt - 4 PCS...
  • Page 7 Step 4. Attach LEG FRAMES (A) to TOP PANEL (C) using 28MM SCREWS (1) as shown. C Top Panel - 1 PC 1 28mm Screw - 4 PCS...
  • Page 8 Step 5. Attach CASTERS (F) and LOCKING CASTER (E) to each LEG FRAME (A) using WRENCH (4) as shown. A Leg Frame - 2 PCS E Locking Caster - 2 PCS F Caster - 2 PCS 4 Wrench - 1 PC...
  • Page 9 Step 6. Unfold NON-WOVEN BIN (G) and put the BOTTOM BIN SUPPORT (H) into NON-WOVEN BIN (G) as shown. G Non-Woven Bin - 3 PCS H Bottom Bin Support - 3 PCS...
  • Page 10 Step 7. Repeat Step 6 to assemble the two remaining NON-WOVEN BINS (G) and place them onto the shelves as shown. FINISHED FINISHED To clean the side table, wipe with soft, dry cloth. Apply a small amount of cleaning solution to the cloth if required. Do not use abrasive cleaners in order to prevent 20 lbs.
