- Page 1 Instruction Manual for Bread slicer CC44B INSTRUCTION MANUAL BREAD SLICER www.allaboutbakery.com.au...
-
Page 2: Table Of Contents
Instruction Manual for Bread slicer CC44B MODEL: CC44B Contents 1. General Information: 1- Documentation supplied: 2- Contact details 3- Use of this manual 4- Intellectual property rights 5- Warranty terms and conditions 6- Machine specifications 7- Machine identification details 8- Main components of the machine... -
Page 3: General Information
Instruction Manual for Bread slicer CC44B 1. General Information: 1.1 Documentation supplied • Instruction manual • Spare parts list • Wiring diagrams 1.2 Contact Details International Bakery Equipment Pty Ltd (I.B.E.) Address: 19B Flinders Parade North Lakes Queensland Australia 4509... -
Page 4: 4- Intellectual Property Rights
Instruction Manual for Bread slicer CC44B 1.4 Intellectual Property Rights This manual contains copyright information. All rights are reserved. No part of this manual can be reproduced or photocopied without prior written permission of International Bakery Equipment Pty Ltd. Permission to use this documentation has only been given to the customer who this manual has been supplied as part of the machine’s equipment and only for... -
Page 5: 5- Warranty Terms And Conditions
Instruction Manual for Bread slicer CC44B 1.5 Warranty Terms and Conditions • Warranty becomes effective from date of delivery. • Warranty claims may be made by telephone, letter, email or fax. However all verbal claims must be confirmed in writing. I.B.E. -
Page 6: 6- Machine Specifications
Instruction Manual for Bread slicer CC44B 1.6 Specifications Crate Dimensions: Length (cm) Width (cm) Height (cm) Weight (Kg) Machine Specifications Loaves per Dimensions Weight Motor Model Hour (app) (Net) CC44B 62 69 76 Power Supply Details: Single Phase, 10amp 3-pin plug top (supplied) Note: Loaves per hour are dependant on the slicer operator. -
Page 7: 7- Machine Identification Details
Instruction Manual for Bread slicer CC44B 1.7 Machine Identification Details Type: Bread Slicer Model: CC44B Position of Serial Number Identification Plate (Fig 1.1) Serial number Identification plate Fig 1.1 Note: When requesting spare parts please state the serial number found on the serial number identification plate. -
Page 8: 8- Main Components Of The Machine
Instruction Manual for Bread slicer CC44B 1.8 Main Machine Components Bagging Spoon In feed shute and cover Slicing Blades On/Off switch Out Feed shute, with Guides Bread crumb Draw Optional Stand Fig 1.2 Machine components Measurments www.allaboutbakery.com.au... - Page 9 Instruction Manual for Bread slicer CC44B 1.9 Safeguards This machine has been fitted with safeguards to ensure safe operation of this machine, in accordance please ensure the following; • Do not place foreign objects down the in-feed shute. • Ensure training in the safe operation of this machine is carried out with all operators.
- Page 10 Instruction Manual for Bread slicer CC44B In feed Shute cover. The in feed shute is supplied with a stainless steel cover which should be attached to the machine during operation (Fig1.4) Fig 1.4 in feed shute cover fitted to slicer.
-
Page 11: Transport And Installation
Instruction Manual for Bread slicer CC44B 2. Transport and Installation: 2.1 Transport The instructions given in this section must be carefully followed when transporting the machine. This operation may include but is not limited to the following: • Storage of the machine •... -
Page 12: 3- Testing & Safeguards
Instruction Manual for Bread slicer CC44B Fig 2.1 2.2 Installation • Ensure transport crate and all protective packaging is removed. • Carefully clean the machine using a damp clean cloth, removing dust on all surfaces. • When the machine has been unpacked, check the condition of the machine. Any visible damage indicates that the machine has been dropped or hit by something during transport. -
Page 13: 2- Control Panel Components
Instruction Manual for Bread slicer CC44B 3.2 Control Panel components Fig 3.1 TM20B Control Panel Location Description Operation Performed Start / Stop Rocker Switch Starts and stops the machine. Power indicator When lit there is power to the machine. www.allaboutbakery.com.au... - Page 14 Instruction Manual for Bread slicer CC44B 3.3 Operation • Place the loaves on the in feed shute. • Adjust the top comb to rest on top of the loaf and the two in feed guides to guide the loaves down the shute and through the slicing blades. Fig 3.2 Top Comb Fig 3.2...
-
Page 15: Cleaning & Maintenance
Instruction Manual for Bread slicer CC44B 4. Cleaning &Maintanance: 4.1 Cleaning • Always turn power off at the wall and unplug machine prior to any cleaning or maintenance procedures to be carried out. • Keeping the machine cleaned helps to maintain the efficient hassle free operation of the machine. - Page 16 Instruction Manual for Bread slicer CC44B 4.3 Spare Parts List Description Description Left wall Top comb Right wall Fixing plate Front knife frame Thumb screw Fixation pole for right and Rear knife frame left walls Top frame pin Stainless steel top cover...
- Page 17 Instruction Manual for Bread slicer CC44B 4.4 Exploded Parts Drawing www.allaboutbakery.com.au...
- Page 18 Instruction Manual for Bread slicer CC44B 4.5 Electrical Wiring Diagram Power indicator lamp On / Off switch Limit switch Earth wire Motor www.allaboutbakery.com.au...
- Page 19 Instruction Manual for Bread slicer CC44B www.allaboutbakery.com.au...
