- Page 1 Quick Start Guide 15202-1.3_MANUAL_Quickstart_HDI-100-Series-BarrelJack-Cable...
- Page 2 Physical capturing unit for capturing 3D data (some assembly is required) Downloading FlexScan3D Software The HDI 100 Series 3D Scanner is powered by FlexScan3D. You can download the software from the Download Center (downloads.lmi3d.com). To create a download account, please send your contact name, email address, company name, and scanner model to orders@lmi3D.com.
- Page 3 Refer to the FlexScan3D user manual for information on installing and using the FlexScan3D software at http://manual.lmi3d.com. When you receive your HDI 100 Series 3D Scanner, check that these items are included: HDI 100 Series Scanner, Blue LED (HDI 120 shown)
- Page 4 Set Up the Table-top Tripod and Mount the Scanner • Spread the Table-top Tripod legs and place them on a flat, stable surface. • Attach the HDI 100 Series Scanner to the Table-top Tripod head by hand-tightening the head knob. Head knob...
- Page 5 Connect the Cordset to the Scanner • Connect the Power and Ethernet Cordset to the Power/LAN connector on the Scanner • Hand-tighten the cordset. Connect Power and Ethernet Cordset to Power Supply • Connect the Power barrel jack of the Power and Ethernet Cordset to the Power Supply...
- Page 6 The Power and LED indicators should light when you plug the power supply in. (Consult the User Manual for troubleshooting tips if the indicators do not light.) The physical assembly of the HDI 100 Series 3D Scanner is now complete...
- Page 7 Flexscan3D software at http://manual.lmi3d.com. LMI Technologies, their partners, and resellers accept no liability for any damages (personal or to property) incurred as a result of improper use, incorrect assembly, failure to adhere to safety precautions, and/or mistreatment of this product (including its...
- Page 8 Copyright © 2015 LMI Technologies Inc. All rights reserved.
