1

RTU300 GENERAL INFORMATION

1.1 Physical Interfaces

Figure 3 RTU300 Connector and Physical Interfaces
1
Digital Input GND Connection
2
Analog Output Connections
3
Analog GND Connection
4
Analog Input Connection
5
RS485 Connections
6
RS-232 GND Connections
7
Rs232 TX-RX Connections
8
Empty
9
Empty
10
Relay Connections
11
CANBUS Connection
12
Digital Input Connections
13
Digital Output Connections
14
Digital Output Supply(Vin) Connection
15
Digital Output GND Connection
7
16
Device Power (V+) Connection
17
Device Power (V-) Connection
18
Ethernet Port
19
USB Port
20
Relay Status Information LED
21
Digital Output Status Information LED
22
Digital Input Status Information LED
23
System Power LED
24
System Running LED
25
System Error LED
26
Protocol Data Transfer LED
27
Antenna Connection
28
SIM Card Slot
29
SD Card Slot
RTU300 SERIES – HARDWARE MANUAL
